    Product Details:

    Place of Origin: China air-cooled water chillers
    Brand Name: RS or OEM
    Certification: CE for China air-cooled water chillers manufacturer
    Model Number: RS--8A

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set of air-cooled water chillers
    Price: contact us for air-cooled water chiller price
    Packaging Details: standard export packing of industry air-cooled water chillers
    Delivery Time: 15 days according to air-cooled water chiller production
    Payment Terms: T/T, West Union,MoneyGram,L/C etc
    Supply Ability: 500 sets of air-cooled water chillers according to China Manufacturer ability
    Contact Now
    Detailed Product Description
    Keywords: China Air-cooled Chillers Supplier, China Air-cooled Water Chillers Manufacturer, Keyword: China Industrial Chillers OEM Factory; China Industrial Chillers OEM Plant
    Cooling Capacity: 22790 Kcal/h Compressor Power: 8hp
    Type Of Gas: R22 ,R304, R410 Etc Pump Power: 2 Hp
    Flow Rate: 360 L/min

    Item No.: RS-8A

     Air Cooled Industrial Water Chiller/ Air Cooled Water Chiller with Low Degree Temperature manufacturer agent needed



    Description of the air cooled water chillers,

    The air-cooled water chillers use a single closed-loop design for pressurized refrigerant. All models are equipped with compressor and motor overload protection, phase shortage and reversal alarms, anti-freeze thermostat, pressure gauges etc. They feature excellent performance and a long lifespan. The series of working flow is based on the basic principle of heat exchange. It is applicable to the industry that requires flow of precisely controlled chilled water, and considered as indispensable equipment for modern industry.

    Air Cooled Industrial Water Chiller/ Air Cooled Water Chiller with Low Degree Temperature manufacturer agent needed



    Features of the air cooled water chillers,

    Cooling capacity from 7℃ to 35℃.

    Stainless insulated water tank and anti-freeze thermostat.

    R22 refrigerant used as standard for efficient cooling.

    Compressor and pump overload relays.

    Italian made temperature controller maintains an accuracy of±1℃.

    Compact design, easy to operate and maintain.

    Low pressure pumps are standard configurations, while middle or high pressure pumps are optionally available.

    Level meter of water tank is available as an option.

    All adopt Copeland compressors.

    TIC-A adopts tube-fin condenser design without any need of cooling water for excellent heat transfer and rapid cooling.

    Upon request, it can be built to comply with worldwide electrical safety standards (For example, CE,UL,CSA,JIS etc.).



    Specification of the air-cooled water chillers,

    Air Cooled Industrial Water Chiller/ Air Cooled Water Chiller with Low Degree Temperature manufacturer agent needed

    Note,

    1) Refrigeration capacity is tested under the condition that cold water outlet temperature is at 12℃ and ambient

    2)      A piston type compressor is used when power supply is 3⊙, 230V.( TIC-3A-TIC-5A ).

    3)      Environment-friendly R407 C refrigerant is optional.( Model denotes ''U”, such as TIC-5A-U ).

    4)      This pump is   used as standard either for domestic or Southeast Asia; medium ( Model denotes "P", such as TIC-5A-P ) or high pressure pump ( Model denotes “HP", such as TIC-5A-HP )are optional for installation on customer's demands.

    5)      Air-cooled chillers are best to be used in the environment with ambient temperature under 35℃.

    Demands on special voltage of power supply could be satisfied.



    Structure of the air-cooled water chillers,

       Air Cooled Industrial Water Chiller/ Air Cooled Water Chiller with Low Degree Temperature manufacturer agent needed

    Air Cooled Industrial Water Chiller/ Air Cooled Water Chiller with Low Degree Temperature manufacturer agent needed

    1),Stainless iron water tank for storage of circulation water.

    2), Heavy duty 3-phase pump ensures no blockages and high torque.

    3),High/low system pressure gauges.

    4),Main power switch.

    5),Pump pressure gauge.

    6),Scroll/ piston type compressor(s) for super high efficiency and low noise.

    7), Refrigerant tank is fixed to make full use of the condenser cooling fin.

    8),Expansion valve for accurate adjustment of R22 refrigerant.

    9),Tube - fin condenser features quick heat transfer and heat radiation.

    10),Tube-in-shell evaporator ensures efficient cooling.

    11), Powder coated frame.



    Working principle of the air-cooled water chillers,

    Air Cooled Industrial Water Chiller/ Air Cooled Water Chiller with Low Degree Temperature manufacturer agent needed

    TIC-A air-cooled water chillers include four main components, such as compressor, condenser, thermostatic expansion valve and evaporator. The system adopts a single closed-loop design for refrigeration system. Refrigerant is alternatively changed from gaseous to liquid state to absorb or release heat thus a cooling effect is achieved.

    When the machine is started, compressor starts working. Refrigerant is compressed into high pressure and high temperature gas in the process from A to B. In the process From B to C and D, this high pressure and high temperature gas is cooled when it is passing through the condenser and changed into liguid. Heat is taken away by the cooling air. In the process from D to E, the pressure of liquid refrigerant is reduced by expansion valve and a part of the refrigerant is changed from liquid to gaseous state. In the process from E to A, refrigerant absorbs the heat of process water in the evaporator and returns back to the compressor. This heat exchange process repeats until process water is cooled down to required temperature.



    Size of the air-cooled water chillers,

    Air Cooled Industrial Water Chiller/ Air Cooled Water Chiller with Low Degree Temperature manufacturer agent needed

    Air Cooled Industrial Water Chiller/ Air Cooled Water Chiller with Low Degree Temperature manufacturer agent needed



    Model Selection Guide of the air-cooled water chillers,

    Molding machine

    Clamping

    Force (T)

    Forming

    ability

    Kg/hr

    Model No.

    Model No.

    ≤250

    ≤25

    TIC-3W

    TIC-3A

    ≤350

    ≤35

    TIC 5W

    TIC 5A

    ≤450

    ≤45

    ≤550

    ≤55

    TIC-8W

    TIC-8A

    ≤650

    ≤65

    ≤850

    ≤85

    TIC-10W

    TIC-1 OA

    ≤1000

    ≤100

    TIC-12. 5W

    TIC-12. 5A

    ≤1300

    ≤130

    ≤1500

    ≤150

    TIC-15W

    TIC-15A

    ≤1800

    ≤180

    ≤2200

    ≤220

    TIC-20W

    TIC-20A

    ≤2500

    ≤250

    ≤3000

    ≤300

    TIC-25W

    TIC-25A

    ≤4000

    ≤400

    TIC-30W

    TIC-30A

    ≤5000

    ≤500

    TIC-40W

    TIC-40A

    ≤6000

    ≤600

    TIC-45W

    TIC-45A

    ≤7000

    ≤700

    TIC-50W

    TIC-50A





    Machine color--- blue or white, or others;



    Machine brand--- factory brand, OEM brand or no brand;





    We do OEM!



    We do B2B, B2C!
