    Product Details:

    Place of Origin: China air-cooled water chillers
    Brand Name: RS or OEM
    Certification: CE for China air-cooled water chillers manufacturer
    Model Number: RS-L5AL

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set of air-cooled water chillers
    Price: contact us for air-cooled water chiller price
    Packaging Details: standard export packing of industry air-cooled water chillers
    Delivery Time: 15 days according to air-cooled water chiller production
    Payment Terms: T/T, West Union,MoneyGram,L/C etc
    Supply Ability: 500 sets of air-cooled water chillers according to China Manufacturer ability
    Contact Now
    Detailed Product Description
    Product: China Air-cooled Chillers Supplier, China Air-cooled Water Chillers Manufacturer, Keyword: China Industrial Chillers OEM Factory; China Industrial Chillers OEM Plant
    Condition: New -25℃ Low Temperature Air-cooled Chillers Warranty: One Year For -25℃ Low Temperature Air-cooled Chillers

    Item No.: RS-L5AL



    5HP -25℃ Low Temperature Air-cooled Chillers OEM Supplier/ Hot sell air cooled chiller industrial water chiller price





    If you need the price of the Low Temperature Air-cooled Chillers, please do send an E-mail to: 15113320579@vip.126.com



     Home Page





    Description of the air cooled low temperature chillers,

    The air-cooled low temperature chillers use a single closed-loop design for pressurized refrigerant. All models are equipped with compressor and motor overload protection, phase shortage and reversal alarms, anti-freeze thermostat, pressure gauges etc. They feature excellent performance and a long lifespan. The series of working flow is based on the basic principle of heat exchange. It is applicable to the industry that requires flow of precisely controlled chilled water, and considered as indispensable equipment for modern industry.

     5HP -25℃ Low Temperature Air-cooled Chillers OEM Supplier/ Hot sell air cooled chiller industrial water chiller price





    Features of the air cooled low temperature chillers,

    1.Selected world class famous compressor for low-temperature refrigeration

    2.Environment-friendly refrigerant R407C,R134A,R410A,etc,no harm to the ozone field and provide excellent cooling effects.

    3.Options for temperature range: chilled water between – 5℃-30℃(depending on production needs to adopt different system configurations)

    4. According to different needs, optional for various of cooling medium (chilled water): ethylene glyco, clcohol, alcohol ternary mixture etc.; the evaporator designed as anti-corrosive and with calcium chloride water.

    5. Designed for 24 hours non-stop working condition to provide continuous cold source for all kinds of production processes.

    6. Cooling system can be built with cold water tank and circulating pump, no need for cooling tower and cooling water pumps-easy installation and maintenance.

    7. Equipped with various safety devices, providing stable performance with low noise and long life; LCD control panel enables simple and easy operations with visions of working conditions.



    5HP -25℃ Low Temperature Air-cooled Chillers OEM Supplier/ Hot sell air cooled chiller industrial water chiller price







    Specification of the air-cooled low temperature chillers,



    Model Unit RS-L3AL RS-L5AL RS-L8AL RS-L10AL
    Cooling Capacity KW 1.17 1.84 3.85 5.41
    Kcal/h 1005 1584 3310 4651
    Compressor Input power KW 2.25 3.75 6 7.5
    Ralated power HP 3 5 8 10
    Type   Hermetic Scroll (Piston Type)
    Total Input Power KW 3.18 4.86 7.25 9.4
    Power   3HP-380V/50HZ(200V/220V/415V/460V 50HZ/60HZ)
    Evaporator Type   Shell and Tube/Plate Heat Exchanger
    Pipe diameter inch 1"
    Chilled fluid flow m3/h 0.57 0.89 1.86 2.61
    Refrigerant Type   R22(R404A/R507)
    Control Method   Expansion Valve
    Condenser Type   Finned Copper Tube+Low Noise Orter Fan

    Pump Power KW 0.75 0.75 0.75 1.1
    HP 1 1 1 1.5
    Distance m 18 18 18 20
    Safty Protection   High and low Pressure Protection,Over Load Protection,Over Temperature Protection,Phase Sequence Protection etc.
    Dimensions (L*W*H) Air Cooled mm 960*630* 1073 1280*630* 1180 1550*830* 1543 1550*830*1543



    5HP -25℃ Low Temperature Air-cooled Chillers OEM Supplier/ Hot sell air cooled chiller industrial water chiller price



    Model Unit RS-L12AL RS-L15AL RS-L20AL RS-L25AL RS-L30AL RS-L40AL
    Cooling Capacity KW 5.8 6.03 10.03 12.29 14.46 18.45
    Kcal/h 4988 5184 8628 10570 12435 15863
    Compressor Input power KW 4.5*2 11.25 15 18.75 22.5 30
    Ralated power HP 12 15 20 25 30 40
    Type   Hermetic Scroll (Piston Type)
    Total Input Power KW 10.9 13.47 18.8 22.55 28.5 36
    Power   3HP-380V/50HZ(200V/220V/415V/460V 50HZ/60HZ)
    Evaporator Type   Shell and Tube/Plate Heat Exchanger
    Pipe diameter inch 1"
    Chilled fluid flow m3/h 2.8 2.91 4.85 5.94 6.99 8.92
    Refrigerant Type   R22(R404A/R507)
    Control Method   Expansion Valve
    Condenser Type   Finned Copper Tube+Low Noise Orter Fan

    Pump Power KW 1.1 1.5 2.2 2.2 4 4
    HP 1.5 2 3 3 5 5
    Distance m 20 20 20 20 25 20
    Safty Protection   High and low Pressure Protection,Over Load Protection,Over Temperature Protection,Phase Sequence Protection etc.
    Dimensions (L*W*H) Air Cooled mm 1550*830* 1543 1850*1000* 1640 2150*1000* 1820 2400*1150* 1840 2600*1150* 1940 2150*2000* 1820



    Note,

    1. Cooling Capacity is calculated based on: inlet/outlet chilled fluid temperature:12 ℃/7 ℃, inlet/outlet cooling water temperature: 30 ℃/35 ℃.

    2. Working condition: Chilled fluid temperature: from 5 ℃ to 35 ℃. Inlet/outlet chilled fluid Temperature difference: from 3 ℃ to 8 ℃ Cooling water temperature: from 18 ℃ to 37 ℃, Inlet/outlet cooling water Temperature difference: from 3.5 ℃ to 10 ℃.

    We reserve the right to modify above information without prior notice.



    5HP -25℃ Low Temperature Air-cooled Chillers OEM Supplier/ Hot sell air cooled chiller industrial water chiller price



    Machine color--- blue or grey white and black, or others;



    Machine brand--- factory brand, OEM brand or no brand;





    We do OEM!



    We do B2B, B2C!
