Place of Origin: | China honeycomb Desiccant dehumidifier |
Brand Name: | RS or OEM |
Certification: | CE for honeycomb dehumidifier manufacturer |
Model Number: | RS-200H |
Minimum Order Quantity: | 1 set of China honeycomb desiccant rotoe dehumidifier from Manufacturer |
---|---|
Price: | contact factory for good price |
Packaging Details: | standard supplier export packing of China dehumidifiers |
Delivery Time: | 10 days according to honeycomb desiccant rotor dehumidifier manufacturer production |
Payment Terms: | T/T, West Union,MoneyGram,L/C etc |
Supply Ability: | 500 sets of dehumidifiers according to China Manufacturer ability |
Keywords: | China Dehumidifiers OEM Factory, China Dehumidifying Dryer; | Keyword: | China Honeycomb Dehumidifier Manufacturers |
---|---|---|---|
Air Flow: | 200m3/hr |
Item No.: RS-200H
China Industrial Dehumidifiers / plastic Desiccant ROTOR dehumidifier dryer machine factory price
pls send inquiry to 13590932590@vip.126.com
Description of the China honeycomb dehumidifier,
The honeycomb dehumidifiers are mainly used to dry hygroscopic engineering plastics. A honeycomb-rotor is used in this series to offer effective drying. We offer two types of honeycomb rotors:H4 and H5 models that, under ideal conditions, can supply dehumidified dry air with a dew-point down to -40?and -50?respectively.The TD-H series offers accurate P.I.D temperature control as optional features. This series comprises 14 models of honeycomb dehumidifiers, the largest of which can provide dry air up to a volume of 4000m3/hr.
Features of the China honeycomb dehumidifier,
The honeycomb dehumidifiers use P.I.D temperature control system, has regenerating temperature settings and real temperature display function.
Equips with dehumidifying heater and temperature control gauge as options to dry and dehumidify the raw material.
The dehumidifying system features two condensers to ensure a low return air temperature and low dew-point,
Main power switch with mechanical chain lock function.
Specification of the honeycomb dehumidifier,
Model |
30H |
50H |
80H |
120H |
150H |
200H |
300H |
400H |
500H |
700H |
1000H |
1500H |
2000H |
3000H |
Process Air Flow ( rrf/hr) |
30 |
50 |
80 |
120 |
150 |
200 |
300 |
400 |
500 |
700 |
1000 |
1500 |
2000 |
3000 |
Process Heater (kw)
|
3 |
3.9 |
6 |
6 |
7.2 |
12 |
15 |
18 |
21 |
24 |
32 |
58 |
80 |
96 |
Process Blower ( kw)
|
0.2 |
0.4 |
0.75 |
0.75 |
1.5 |
1.5 |
3 |
3.4 |
5.5 |
5.5 |
9 |
9x2 |
13x2 |
13x3 |
(
Regen .heater kw) |
0.2 |
0.2 |
0.2 |
0.2 |
0.4 |
0.4 |
0.75 |
0.75 |
1.5 |
1.5 |
2.4 |
3.4 |
5.5 |
7.5 |
Regen. Blower (kw)
|
3 |
3 |
3.5 |
3.5 |
4 |
5.4 |
7.2 |
7.2 |
10 |
10 |
15 |
20 |
20 |
30 |
Pipe Dia. t ( inch ) |
2" |
2" |
2" |
2" |
2.5" |
2.5" |
3" |
3" |
4" |
4" |
5" |
6" |
8" |
8" |
Voltage |
3⊙,380V,50Hz |
|||||||||||||
Dimensions |
||||||||||||||
H(mm) |
1260 |
1260 |
1360 |
1360 |
1560 |
1560 |
1745 |
1745 |
1935 |
1935 |
2145 |
2145 |
2060 |
2500 |
W(mm) |
480 |
480 |
530 |
530 |
660 |
660 |
700 |
700 |
900 |
900 |
1300 |
1300 |
1410 |
1600 |
D(mm) |
755 |
755 |
820 |
820 |
1050 |
1050 |
1255 |
1255 |
1380 |
1380 |
1550 |
1910 |
2150 |
2160 |
Weight( kg ) |
80 |
80 |
120 |
140 |
215 |
225 |
240 |
280 |
290 |
300 |
400 |
510 |
630 |
760 |
Note:*Process heater is optional to be used with a drying hopper.
Note: we reserve the right to change specification without prior notice.
Machine color--- blue or white, or others;
Machine brand--- factory brand, OEM brand or no brand;
We do OEM!
We do B2B, B2C!
RS Plastics Machinery Co.,LTD (Zhongshan·China) |
|||
Contact Person |
Mrs. Pearl Zhu |
Position |
Export Manager |
|
0086-13590932590 |
|
263567704 |
Wechat APP |
zhhy18 |
Skype |
PEARL20128 |
E-mail-1 |
|||
E-mail-2 |
|||
Website |
For more details of the China honeycomb dehumidifier, please contact us for E-sheets!
For more choice of China dehumidifier manufacturer products, please contact us for E-catalogue and Price Lists!
If there are any questions on China plastic machinery, please feel free to contact us.
We can provide all kinds of China plastics machinery manufacturer solutions to meet your special demands accordingly at one-stop purchasing!
