Home ProductsWater cooled Industry water chillier

25HP Environmental Friendly Water Cooled Chillers/China water cooled water chiller for aquarium temperature control

25HP Environmental Friendly Water Cooled Chillers/China water cooled water chiller for aquarium temperature control

    • 25HP Environmental Friendly Water Cooled Chillers/China water cooled water chiller for aquarium temperature control
    • 25HP Environmental Friendly Water Cooled Chillers/China water cooled water chiller for aquarium temperature control
    • 25HP Environmental Friendly Water Cooled Chillers/China water cooled water chiller for aquarium temperature control
    • 25HP Environmental Friendly Water Cooled Chillers/China water cooled water chiller for aquarium temperature control
  • 25HP Environmental Friendly Water Cooled Chillers/China water cooled water chiller for aquarium temperature control

    Product Details:

    Place of Origin: China Environmental Friendly chillers
    Brand Name: RS or OEM
    Certification: CE for China Environmental Friendly chillers manufacturer
    Model Number: RS-L25W-R7/RO

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set of Environmental Friendly chillers
    Price: contact us for Environmental Friendly chiller price
    Packaging Details: standard export packing of industry water chillers
    Delivery Time: 15 days according to Environmental Friendly chiller production
    Payment Terms: T/T, West Union,MoneyGram,L/C etc
    Supply Ability: 500 sets of Environmental Friendly chillers according to China Manufacturer ability
    Contact Now
    Detailed Product Description
    Product: Environmental Friendly Chillers, China Water-cooled Chillers Supplier, China Water-cooled Water Chil Keyword: China Industrial Chillers OEM Factory; China Industrial Water Chillers OEM Plant;
    Condition: New Environmental Friendly Chillers Warranty: ONE Year For Environmental Friendly Chillers

    Item No.: RS-L25W-R7/R0





     25HP Environmental Friendly Water Cooled Chillers/China water cooled water chiller for aquarium temperature control




    If you need the price of the Environmental Friendly Chiller price, please do send an E-mail to: 13590932590@vip.126.com

    Home Page




    Description of the  Environmental Friendly Chillers,


    The  Environmental Friendly Chillers use a single closed-loop design for pressurized refrigerant. All models are equipped with compressor and motor overload protection, phase shortage and reversal alarms, anti-freeze thermostat, pressure gauges, etc. They feature excellent performance and a long lifespan. The series of working flow is based on the basic principle of heat exchange. It is applicable to the industry that requires flow of precisely controlled chilled water, and considered as indispensable equipment for modern industry.

     25HP Environmental Friendly Water Cooled Chillers/China water cooled water chiller for aquarium temperature control




    Features of the Environmental Friendly Chillers,

    l. Selected world class famous hermetic scroll compressor, with lower noise and less vibration, efficient and energy saving.

    2. Environment-friendly refrigerant R407C, R134A, R410A etc, no harm to the ozone field.

    3. SISMENS electrical parts ensure stable running and liability of the machine.

    4.         Well-known brand pumps, with large working range, low noise, reliable performance and no leakage.

    5.         High-quality       stainless steel tanks and piping system, ensuring water purity and easy maintenance.

    S. Cooling Capacity range from 2KW-2500KW,with various models, can fully meet the demands of industrial production.
    7. Europeanization designed exterior with electrostatic spray coating, simple structure and elegant.

    25HP Environmental Friendly Water Cooled Chillers/China water cooled water chiller for aquarium temperature control



    Specification of the  Environmental Friendly Chillers,


    Model Unit RS-L3W-R7 RS-L5W-R7 RS-L6W-R7 RS-L8W-R7 RS-L10W-R7 RS-L12W-R7
    RS-L3W-R0 RS-L5W-R0 RS-L6W-R0 RS-L8W-R0 RS-L10W-R0 RS-L12W-R0
    Cooling Capacity KW 8.61 14.5 17 23.2 29 33.2
    Kcal/h 7405 12470 14672 19952 24940 28569
    Compressor Input power KW 2.68 4.48 5.2 3.5x2 4.5x2 5.2x2
    Ralated power HP 3 5 6 4x2 5x2 6x2
    Power   3HP-380V/50HZ(200V/220V/415V/460V 50HZ/60HZ)
    Evaporator Type   Water Tank with Coil(shell and Tube)
    Pipe diameter inch 1" 1" 1" 2" 2" 2"
    Refrigerant Type   R407C(R410A)
    Control Method   Capillary Tube (Capillary)Expansion Valve
    Condenser Type   Shell Condenser
    Pipe diameter inch 1-1/2" 1-1/2" 1-1/2" 2" 2" 2"
    Cooling Water Flow m3/h 1.36 2.22 2.6 3.95 4.42 5.03
    Water tank capacity Liter 50 60 60 110 110 110
    Pump Power KW 0.37 0.37 0.75 0.75 0.75 0.75
    HP 0.5 0.5 1 1 1 1
    Distance m 23 23 35 13 13 13
    Flow Rate L/min 100 100 110 200 200 200
    Safty Protection   High and low Pressure Protection,Over Load Protection,Over Temperature Protection,Phase Sequence Protection etc.
    Dimensions (L*W*H) mm 935*500* 883 935*500* 883 935*500* 883 1270*650 *1413 1270*650 *1413 1270*650 *1413


    25HP Environmental Friendly Water Cooled Chillers/China water cooled water chiller for aquarium temperature control





    Model Unit RS-L15W-R7 RS-L20W-R7 RS-L25W-R7 RS-L30W-R7 RS-L40W-R7 RS-L50W-R7
    RS-L15W-R0 RS-L20W-R0 RS-L25W-R0 RS-L30W-R0 RS-L40W-R0 RS-L50W-R0
    Cooling Capacity KW 44 57.6 67 94.8 117.2 142
    Kcal/h 38081 49533 67620 81528 100792 122636
    Compressor Input power KW 6.75x2 9x2 10x2 12.5x2 16.7x2 20.4x2
    Ralated power HP 7.5x2 10x2 12.5x2 15x2 20x2 25x2
    Power   3HP-380V/50HZ(200V/220V/415V/460V 50HZ/60HZ)
    Evaporator Type   Water Tank with Coil(shell and Tube)
    Pipe diameter inch 2" 2.5" 2.5" 3" 3" 3"
    Refrigerant Type   R407C(R410A)
    Control Method   Capillary Tube (Capillary)Expansion Valve
    Condenser Type   Shell Condenser
    Pipe diameter inch 2" 2.5" 2.5" 3" 3" 3"
    Cooling Water Flow m3/h 7.1 8.84 10.06 13.6 17.75 21.9
    Water tank capacity Liter 200 350 350 420 420 420
    Pump Power KW 1.5 1.5 2.2 2.2 4 4
    HP 2 2 3 3 5 5
    Distance m 15 15 16 16 16 16
    Flow Rate L/min 360 360 650 650 700 700
    Safty Protection   High and low Pressure Protection,Over Load Protection,Over Temperature Protection,Phase Sequence Protection etc.
    Dimensions (L*W*H) mm 1270*750 *1413 1880*880*1650 1880*880 *1650 1880*880*1650 2150*1080 *1950 2150*1080 *1950



    Note,

    Note: 1.Cooling Capacity is calculated based on: inlet/outlet chilled fluid temperature:12℃/7℃,inlet/outlet cooling water temperature:30℃/35℃.

    2.Working condition: Chilled fluid temperature: from 5℃ to 35℃. Inlet/outlet chilled fluid Temperature difference: from 3℃ to 8℃

    Cooling water temperature: from 18℃ to 37℃, Inlet/outlet cooling water Temperature difference: from 3.5℃ to 10℃.

    We reserve the right to modify above information without prior notice.

    Demands on special voltage of power supply could be satisfied.


     25HP Environmental Friendly Water Cooled Chillers/China water cooled water chiller for aquarium temperature control



    Machine color--- blue or gray white and black, or others;



    Machine brand--- factory brand, OEM brand or no brand;



    We do OEM!



    We do B2B, B2C!





    RS Plastics Machinery Co.,LTD   (Zhongshan·China)

    Contact Person

    Mrs. Pearl Zhu

    Position

    Export Manager

    whatsApp

    0086-13590932590

    QQ

    263567704

    Wechat

    zhhy18

    Skype

    PEARL20128

    E-mail-1

    15113320579@vip.126.com

    E-mail-2

    13590932590@vip.126.com

    Website

    http://www.rs-plastics-machinery.org




    For more choice, please click the following,
    water-cooled water chiller;
    Air-cooled chiller;
    central chiller/open type chiller/screw chillers;
    water cooling tower;
    mold temperature controller;



    If you need the price of the Environmental Friendly Chiller price, please do send an E-mail to: 15113320579@vip.126.com
