Pumping Oil Circulation Mold Temperature Controller for Compression Casting/370℃ Die Casting Oil MTC

Pumping Oil Circulation Mold Temperature Controller for Compression Casting/370℃ Die Casting Oil MTC

    • Pumping Oil Circulation Mold Temperature Controller for Compression Casting/370℃ Die Casting Oil MTC
    • Pumping Oil Circulation Mold Temperature Controller for Compression Casting/370℃ Die Casting Oil MTC
    • Pumping Oil Circulation Mold Temperature Controller for Compression Casting/370℃ Die Casting Oil MTC
    • Pumping Oil Circulation Mold Temperature Controller for Compression Casting/370℃ Die Casting Oil MTC
  • Pumping Oil Circulation Mold Temperature Controller for Compression Casting/370℃ Die Casting Oil MTC

    Product Details:

    Place of Origin: China Die Casting oil mold temperature controller
    Brand Name: RS or OEM
    Certification: CE for China Die Casting oil mold temperaturer controller manufacturer
    Model Number: RS-TM-370

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set of Die Casting Oil Mold Temperature Controller
    Price: contact us for Die Casting Oil Mold Temperature Controller price
    Packaging Details: standard export packing of Die Casting Oil Mold Temperature Controller
    Delivery Time: 15 days according to Die Casting Oil Mold Temperature Controller production
    Payment Terms: T/T, West Union,MoneyGram,L/C etc
    Supply Ability: 500 sets of Die Casting Oil Mold Temperature Controller according to China Manufacturer ability
    Contact Now
    Detailed Product Description
    Product: China Die Casting Oil Mold Temperature Controller Manufacturer, China Oil Heaters OEM Factory, Keyword: China Die Casting Industrial Mould Temperature Controllers Supplier;MTC;
    Condition: New Die Casting High Temperature Mold Temperature Controller Warranty: ONE Year For Die Casting High Temperature Mold Temperature Controller

    Item No.: RS-TM-370





     Pumping Oil Circulation Mold Temperature Controller for Compression Casting/370℃ Die Casting Oil MTC





    If you need the price of the 370℃ Die Casting High Temperature Oil Mold Temperature Controller Price, please do send E-mail to: 15113320579@vip.126.com



    Home Page





     370°C DIE CASTING MTC

    CASTING,RUBBER EXTRUSION,FOAMING,AND OTHER SPECIAL MTC SERIES



    Die-casting Mold Temperature Controller

    Introduction: Die-Casting Mold Temperature Controller is high function equipment developed specially for die-casting industry. Comp with competitors,this is with higher performance but more reasonable price and it is the best choice for customers of magnesium,aluminum and die-casting.The advantage of this type controller is processing temperature up to 370 ;designed with advance process;High accuracy in contrc temperature,fast heat exchange,efficient and energy-saving.

    Pumping Oil Circulation Mold Temperature Controller for Compression Casting/370℃ Die Casting Oil MTC





    FEATURE:

    1.         Maximum      running temperature as 370.

    2.         Adopted microcomputer controller, easy to operate .P.I.D. dual-stage temperature control system maintains an accuracy of ±0.1℃

    3.          Main pipes are made of uni-body stainless steel, with uniform heating and low-loss.

    4.         Equipped       with 304 stainless steel high temperature sluice value, with good heat resistant performance.

    5.         With       sufficient safety production and alarming system.

    6.0ptional for high temperature magnetic pump with stable performance and no leakage.

    7.         Adopts   indirect cooling method, which realizes fast heating, makes temperature controller more precise and stable.

    8.         With       automatic shutdown cooling protection function etc.

    9.         With       temperature detecting indication of oil return.

    10.     Multi-machine      parallel is customized.

    11, Sufficient safety protection and visible alarm, easy for maintenance.

    12.Using isolated electric control box, to extend the lives of electric appliances.



    Calculation Formula:

    Heating Power(KW) = mold weight(KG)*mold heat specific (Kcal/KG)*molding temperature difference(℃)x safety factor/heating time/860 Notice: Safety factor ranges from 1.3 to 1.5.

    Flow Rate(L/min) = Heating Power(KW)*860/[medium specific heat(Kcal/KG )*medium density(KG/L)*inlet and outlet temperature difference*time(60)]



    Notice:

    1.         Water     specific heat = lKcal/KG°C

    2.         Heating  Oil specific heat = 0.49Kcal/KG

    3.         Water     density=1KG/L

    4.         Heating  Oil density = 0.842KG/L

    Pumping Oil Circulation Mold Temperature Controller for Compression Casting/370℃ Die Casting Oil MTC





    Specification of the industrial oil mould temperature controllers,



        Model                                Unit             RS-TM18KW-370          RS-TM24KW-370         RS-TM36KW-370

    Temp. Control Range



    370°C



    Temp. Control Accuracy



    p.i.d. ±0.1 ℃



    Power Supply





    AC3 380V 50HZ



    Heat Transfer Medium





    Heat Transfer Oil



    Cooling Method





    Indirect Cooling



    Heating Capacity

    KW

    9x2

    12x2

    12x3

    Pump Power

    KW

    1.5

    2.2

    3.75

     Max. Pump Flow

    L/min

    50

    165

    200

    Max. Pump pressure

    KG/cm2

    2.8

    2.8

    3

    Oil Tank Capacity

    Liter

    30

    30

    30

    Alert Function



    Phase-Missing/Water Insufficient/Over-Heat/Over Current

    Cooling Water Pipe

    mm

    12

    12

    12

    Circulating Oil Pipe

    inch

    (1x1)

    (lxl)

    (lxl)

    Dimension(L*W*H)

    mm

    1325*560*1110

    1325*560*1110

    1325*560*1110

    Approx.Net Weight               KG             205                                         215                           220



    We reserve the right to change specifications without prior notice.



    Pumping Oil Circulation Mold Temperature Controller for Compression Casting/370℃ Die Casting Oil MTC





    Application of the industrial oil mould temperature controllers,



    The  Mold Temperature Controller is suitable for Reaction kettles, extrusion forming equipment, rubber forming machinery, cast film production lines, cable extrusion production lines, the dies for precise plastic molding, the dies for the compression casting of magnesium/aluminum/zinc alloy, roller pressing applied in rubber/plastic and leather industries, crude oil heating of the oil sinks on tank ships, paper making industry, bottle blowing, and so on.



    The  Mold Temperature Control System has been designed to maintain a constant temperature, using water or oil as medium. Mold temperature controller is used to control temperature in various industrial fields.

    Pumping Oil Circulation Mold Temperature Controller for Compression Casting/370℃ Die Casting Oil MTC





    Working Principle of the industrial oil mould temperature controllers,

    High temperature oil returns to the machine and then be pressured by pump to the heaters, After being heated, oil will be forced to mould and continue the circle. In the process, if the temperature is too high, the system will activate the solenoid valve to let return oil cool down the temp, directly till the oil temp, is down to the system requirement. If the temp, keep rising and reach to the set point of EGO, the system will alarm and stop working if cooling water pressure doesn't reach set point.

    Pumping Oil Circulation Mold Temperature Controller for Compression Casting/370℃ Die Casting Oil MTC









    Machine color--- blue or gray white, or others;



    Machine brand--- factory brand, OEM brand or no brand;







    We do OEM!



    We do B2B, B2C!
