3 Phase 380V 50Hz High temperature Oil Mold Temperature Control Machine/300℃ High Temperature Oil MTC

3 Phase 380V 50Hz High temperature Oil Mold Temperature Control Machine/300℃ High Temperature Oil MTC

    • 3 Phase 380V 50Hz  High temperature Oil Mold Temperature Control Machine/300℃ High Temperature Oil MTC
    • 3 Phase 380V 50Hz  High temperature Oil Mold Temperature Control Machine/300℃ High Temperature Oil MTC
    • 3 Phase 380V 50Hz  High temperature Oil Mold Temperature Control Machine/300℃ High Temperature Oil MTC
    • 3 Phase 380V 50Hz  High temperature Oil Mold Temperature Control Machine/300℃ High Temperature Oil MTC
  • 3 Phase 380V 50Hz  High temperature Oil Mold Temperature Control Machine/300℃ High Temperature Oil MTC

    Product Details:

    Place of Origin: China High Temperature oil mold temperature controller
    Brand Name: RS or OEM
    Certification: CE for China High Temperature oil mold temperaturer controller manufacturer
    Model Number: RS-TM-O

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set of High Temperature Oil Mold Temperature Controller
    Price: contact us for High Temperature Oil Mold Temperature Controller price
    Packaging Details: Standard export packing of High Temperature Oil Mold Temperature Controller
    Delivery Time: 15 days according to High Temperature Oil Mold Temperature Controller production
    Payment Terms: T/T, West Union,MoneyGram,L/C etc
    Supply Ability: 500 sets of High Temperature Oil Mold Temperature Controller according to China Manufacturer ability
    Contact Now
    Detailed Product Description
    Product: High Temperature Oil Mold Temperature Controller,China Standard Oil Mold Temperature Controller Manufacturer, China Oil Heaters OEM Factory, Keyword: High Temperature Oil Mold Temperature Controller, China Industrial Mould Temperature Controllers Supplier;MTC;
    Condition: New High Temperature Oil Mold Temperature Controller Warranty: ONE Year For High Temperature Oil Mold Temperature Controller

    Item No.: RS-TM-O





     3 Phase 380V 50Hz High temperature Oil Mold Temperature Control Machine/300℃ High Temperature Oil MTC





    If you need the price of the 300 ℃ High Temperature Oil Mold Temperature Controller price, please do send an E-mail to: 15113320579@vip.126.com



    Home Page





    Features of the Oil Type Mold Temperature Controller,



    1, adopted microcomputer controller, easy to operate, PID dual-stage temperature control system maintains an accuracy of +/- 0.1

    2, With sufficient safety production and alarm system;

    3, Adopts high temperature coupling pump with no leakage of oil;

    4, With automatic shutdown cooling protection function;

    5, With temperature detecting indication of oil return;

    6, Multi-machine parallel is customized;

    7, Main pipes are made of uni-body 304 stainless steel, with uniform heating and low loss;

    8, Equipped with 304 stainless steel high temperature sluice valve;

    9, adopts indirect cooling method which makes temperature controller more precise and stable;

    10, sufficient safety protection and visible alarm, easy for maintenance;

    11, Using isolated electric control box, to extend the lives of electric appliance.

    3 Phase 380V 50Hz  High temperature Oil Mold Temperature Control Machine/300℃ High Temperature Oil MTC





    Specification of the industrial oil mould temperature controllers,



    Model

    Unit

    RS-TM12KW-300

    RS-TM18KW-300                             RS-TM24KW-300

    RS-TM36KW-300

    RS-TM48KW-300

    Temp. Control Range

    °C



    300*C





    Temp. Control Accuracy

    °C



    p.i.d. ±o.1℃





     Power Supply





    AC3 380V 50HZ





    Heat Transfer Medium





    Heat Transfer Oil





    Cooling Method





    Indirect Cooling





    Heating Capacity

    KW

    12

    9x2                         12x2

    12x3

    12x4

    Pump Power

    HP

    1

    2                            2

    3

    5

    Max. Pump Flow

    L/min

    50

    83                            83

    165

    480

    Max. Pump pressure

    KG/cm2

    2

    2.5                              2.5

    2.5

    3

    Oil Tank Capacity

    Liter

    20

    30                                  30

    30

    30

    Alert Function



    Phase-Missing/Water Insufficient/Over-Heat/Over Current



    Cooling Water Pipe

    mm

    12

    12                                     12

    12

    12

    Circulating Oil Pipe

    inch

    (4x4) 3/8

    (lxl)                                 (1x1)

    (lxl)

    (lxl)

    Dimension(L*W*H)

    mm

    1325*560*1110

    1325*560*1110                1325*560*1110

    1325*560*1110

    1325*560*1110



    Approx.Net Weight          KG                    205                             210                             215                             220                             225



    We reserve the right to change specifications without prior notice.



    3 Phase 380V 50Hz  High temperature Oil Mold Temperature Control Machine/300℃ High Temperature Oil MTC



    3 Phase 380V 50Hz  High temperature Oil Mold Temperature Control Machine/300℃ High Temperature Oil MTC





    Application of the industrial oil mould temperature controllers,



    The  Mold Temperature Controller is suitable for Reaction kettles, extrusion forming equipment, rubber forming machinery, cast film production lines, cable extrusion production lines, the dies for precise plastic molding, the dies for the compression casting of magnesium/aluminum/zinc alloy, roller pressing applied in rubber/plastic and leather industries, crude oil heating of the oil sinks on tank ships, paper making industry, bottle blowing, and so on.



    The  Mold Temperature Control System has been designed to maintain a constant temperature, using water or oil as medium. Mold temperature controller is used to control temperature in various industrial fields.

    3 Phase 380V 50Hz  High temperature Oil Mold Temperature Control Machine/300℃ High Temperature Oil MTC





    Working Principle of the industrial oil mould temperature controllers,

    High temperature oil returns to the machine and then be pressured by pump to the heaters, After being heated, oil will be forced to mould and continue the circle. In the process, if the temperature is too high, the system will activate the solenoid valve to let return oil cool down the temp, directly till the oil temp, is down to the system requirement. If the temp, keep rising and reach to the set point of EGO, the system will alarm and stop working if cooling water pressure doesn't reach set point.
