    Product Details:

    Place of Origin: China color mixer
    Brand Name: RS or OEM
    Certification: CE for volumetric double color mixer
    Model Number: RS-TCM-D-30-100

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set of volumetrc dosing color mixer
    Price: contact us for plastics color mixer price
    Packaging Details: standard export packing of volumetric dosers
    Delivery Time: 15 days according to volumetric dosing color mixer production
    Payment Terms: T/T, West Union,MoneyGram,L/C etc
    Supply Ability: 500 sets of volumetric double color mixers
    Contact Now
    Detailed Product Description
    Product: Volumetric Double Color Mixer, Volumetric Dosing Color Mixer, Keyword: Plastic Mixing Machine,volumetric Dosers;
    Condition: New Double Color Volumetric Dosing Mixer Warranty: ONE Year For Volumetric Double Color Mixer

    Item No.: RS-TCM-D-30-100





    China Volumetric Color Dosing Mixer/Double-color Volumetric Dosing Color Mixer For Mexico




    E-mail: 15113320579@vip.126.com

    Home Page




    Description of the volumetric double color mixer,
    The volumetric dosers color mixer are suitable for auto-proportional mixing of new material, regrind, master batch and additives. A brushless DC motor is used in this series. The microprocessor accurately controls rotation of the high precise dosing screws to squeeze out materials with an accuracy of 1% form set point. A gear motor with deceleration ratio of 30:1 or 100:1 is coupled to a dosing screw of six models with output ranging from 0.1~32kg/hr. Double color doser can be supplied to match with two single color doser if required by clients.
     China Volumetric Color Dosing Mixer/Double-color Volumetric Dosing Color Mixer For Mexico

    China Volumetric Color Dosing Mixer/Double-color Volumetric Dosing Color Mixer For Mexico





    Features of the volumetric color mixer

    Everlasting data memorizer and settings storage.
    Use brushless DC motor and free from maintenance.
    Microprocessor control, intelligent and accurate in calculation.
    External signals can be directly interfaced with the control box.
    Dosing screws are chrome plated for durability.
    Unit is comprised of standard modules for ease of cleaning, disassembly and interchangeability.
    Three-tubes hopper magnet is equipped at the base of the single color doser to absorb metal impurities so to prevent the screw of molding machine from damage.
    Single color doser takes base blender as an option to make blending more evenly.
    Blender built-in a standard accessory for double color doser and it can meet client's need for double blending.
    Main material hopper is a standard accessory for double color mixer. It is optional for single color mixer.


    China Volumetric Color Dosing Mixer/Double-color Volumetric Dosing Color Mixer For Mexico




    Specification of the volumetric color mixer,


    Model RS-TCM-D-30/30 RS-TCM-D-30/100 RS-TCM-D-100/100
    Motor Power (KW) 0.06x2 0.06x2 0.06x2
    Rev (r.m.p) 0-3000 0-3000 0-3000
    Mixer Power (KW) 0.09 0.09 0.09
    Screw External Dia (mm) ** ** **
    Output Capacity (kg/hr) * * *
    Storage Bin (L) 10 10 10
    Gear Ratio 30:1/100:1 30:1/100:1 30:1/100:1
    Main Material Hopper standard standard standard
    Mixer standard standard standard
    Floor Stands optional optional optional
    Dimensions
    H (mm) 580 580 580
    W (mm) 900 900 900
    D (mm) 290 290 290
    Weigh (kg) 50 50 50



    Note:1) “ * ” means the output capacity depends on model selected, data of the single color mixer/doser can be a reference. For example: RS-TCM-D-38-16/38-14,output capacity l .7-52kg/hr.

    2)            “ ** ” stands for external dia. of screw is up to model selected.

    3)            Single-color   volumetric mixer adds to mixer, add “MS” at the back of the model.

    4)            AII  output capacity from above models are base on data from density 1.2,dia. 2-3 mm master batch in a test criteria of continuous running.



    5), Voltage:1⊙,220V,50Hz.



    China Volumetric Color Dosing Mixer/Double-color Volumetric Dosing Color Mixer For Mexico



    Machine color--- blue or gray white and black, or others OEM;



    Machine brand--- factory brand, OEM brand or no brand;




    We do OEM!



    We do B2B, B2C!





    RS Plastics Machinery Co.,LTD   (Zhongshan·China)

    Contact Person

    Mrs. Pearl Zhu

    Position

    Export Manager

    Mobile Phone

    0086-13590932590

    QQ

    263567704

    Wechat APP

    zhhy18

    Skype

    PEARL20128

    E-mail

    13590932590@vip.126.com / 15113320579@vip.126.com

    Website

    http://www.rs-plastics-machinery.org




    For more details of the volumetric color mixers, please contact us for E-sheets!

    For more choice of mixers, plastic machinery   products, please contact us for E-catalogue and Price Lists!
