Item No.: RS-GP230
China Flake Type Crusher / Flake Type Plastic Crusher Manufacturer
E-mail: 15113320579@vip.126.com
Home Page
Description of the Flake Type cutter crushers
Our granulators include claw cutter series, flat cutter series, V type cutter sereis, Flake type cutter Series and blade cutter series. They are applicable to a wide range, can meet a wide variety of requirements, able to granulate & recycle all kinds of plastics material of different texture and shapes.
Flake Type Crusher Features,
1, The structure of the tool rest between claw blade knife peace;
2, Hopper double insulation, mute effect is good.
3, The blade with 9 crsi alloy tool steel;
4, Adopt famous brand electrical appliances, motor;
5, Suitable for ordinary piece of material and all kinds of plastic material floolwing.
Specification of the GP Flake Type cutter strong crushers,
| Model |
RS-GP230 |
RS-GP300 |
RS-GP400 |
| Crushing diameter (mm) |
230*200 |
310*200 |
410*240 |
| Crushing capacity (KG/H) |
100-150 |
150-200 |
200-250 |
| The fixed knife |
2 |
2 |
2 |
| Rotating knife |
6 |
9 |
12 |
| KW power |
4 |
5.5 |
7.5 |
| HP |
5 |
7.5 |
10 |
|
Dimension
(L * W * H cm)
|
97*61*120 |
100*70*129 |
103*84*139 |
| Weight (KG) |
290 |
435 |
500 |
| Model |
RS-GP500 |
RS-GP600 |
RS-GP800 |
| Crushing diameter (mm) |
510*300 |
610*330 |
815*470 |
| Crushing capacity (KG/H) |
300-350 |
350-450 |
450-600 |
| The fixed knife |
2 |
4 |
4 |
| Rotating knife |
15 |
18 |
24 |
| KW power |
11 |
15 |
22/30 |
| HP |
15 |
20 |
30/40 |
|
Dimension
(L * W * H cm)
|
123*101*163 |
132*111*183 |
173*149*230 |
| Weight (KG) |
900 |
970 |
2000 |
| Model |
RS-GP960 |
RS-GP1100 |
RS-GP1200 |
| Crushing Diameter (mm) |
960*610 |
1100*800 |
1200*800 |
| Crushing capacity (KG/H) |
800-1000 |
1000-1200 |
1000-1500 |
| The fixed knife |
4 |
6 |
6 |
| Rotating knife |
27 |
30 |
30 |
| KW Power |
37/45/57 |
75 |
75 |
| HP |
50/60/75 |
100 |
100 |
| Dimension(L*W*H cm) |
1950*1760*2740 |
2510*2060*3700 |
2510*2100*3700 |
| Weight (KG) |
3000 |
6000 |
6200 |
Machine color--- blue, green or gray white, or others;
Machine brand--- factory brand, OEM brand or no brand;
We do OEM!
We do B2B, B2C!
For more details of the FlakeType Powerful Granulators/ crusher, please contact us for E-sheets!
For more choice of plastic granulator, plastic crusher, plastic machinery products, please contact us for E-catalogue and Price Lists!
