Detailed Product Description
Keywords: China Hopper Dryer Supplier, China 12kg-1000kg Hopper Dryer Manufacturer, Keyword: China 3 Phases 400V 50Hz Hopper Dryer Manufacturer;

Item No.: RS-THD-12-600

 China 3 Phases 380V 50Hz  White Color Hopper Dryer OEM Producer/Standard Hopper Dryer



E-mail: 15113320579@vip.126.com



Home Page



Description of the China hopper dryer


The China hopper dryers offer an effective and low-cost method for plastic material drying. Hot air is used to dry wet materials due to moisture absorption during packaging, transportation, and recycling. They can be directly mounted on the molding machine for quick drying and space saving. For this series, hot air blows eventually from bottom to the top (both THD-800 and THD-1000 have down-blowing air pipe and accessible door for easy material clearance) of the hopper with capacity ranging from 12kg to 1000kg. All models can be supplied with optional 24 hours auto start/stop timer.

Reference photo of the China hopper dryer,

China 3 Phases 380V 50Hz White Color Hopper Dryer OEM Producer/Standard Hopper Dryer


Features of the China hopper dryer


Adopt hot air diffuser to gain an even hot air flow to improve drying efficiency.
Unique hot air inlet elbow design can prevent dust pilling up at bottom of the pipe heaters so to avoid burning.
All material contact surfaces are made of stainless steel to eliminate material contamination.
Separable hopper base provides easy access to hopper tank for the convenience of material changing and cleaning.
Proportional deviation indicative temperature controller for accurate temperature control.
Overheat protectors to prevent accidents by human error or mechanical faults.
Overheat indicating light, motor contactor and overload relay are equipped standard.
Quick cooling blower and outfitted power switch.
Preheat timer and double insulated hopper are available as options.
More optional accessories: L/A type floor stand, dried-material suction box, hopper magnet, magnetic base, hot air recycler, blower inlet filter, exhausted air filter, and cyclone dust separator.





Specification of the China hopper dryer,

model

THD-12

THD-25

THD-50

THD-75

THD-100

THD-150

THD-200

THD-300

THD-400

THD-500

THD-600

Drying electric heat ( KW )

2.2

3

3.9

4.2

6

6

12

15

18

19.5

21

Air blower ( kw )

0.12

0.12

0.12

0.12

0.18

0.18

0.25

0.25

0.25

0.25

0.55

Material capacity ( kg )

12

25

50

75

100

150

200

300

400

500

600

A(mm)

325

385

470

530

595

595

750

750

910

910

910

B(mm)

660

725

840

900

955

955

1230

1230

1365

1365

1365

C(mm)

865

1015

1145

1240

1340

1580

1750

1985

2105

2285

2530

D(mm)

750

925

1045

1150

1340

1605

1480

1480

1840

1840

2015

E(mm)

360

405

490

550

605

605

770

770

915

915

950

F(mm)

370

460

520

620

725

970

975

1220

1220

1400

1545

H(mm)

110

210

220

220

226

226

258

258

302

302

302

l(mm)

170

170

170

170

166

166

158

158

222

222

222

G(mm)

375

410

380

475

470

470

550

550

775

775

775

K/L(mm)

150

150

150

150

220

220

257

257

345

345

345

M(mm)

55

55

55

55

90

90

90

90

105

105

105

N.W. (kg)

35

40

45

55

70

75

120

120

165

170

240

Drawing of the hopper dryer for model THD-12 to THD-600

 China 3 Phases 380V 50Hz White Color Hopper Dryer OEM Producer/Standard Hopper Dryer

Note

1)Auto-timer, adds “T” to the back of the model.

2)           Magnetic     base, adds “M” to the back of the model.

3)           Double insulated layer, adds “I” to the back of the model.

4)           180       high temperature. Model, adds “H” to the back of the model.

5)           Change       into single phase voltage, adds “S” to the back of the model (apply to THD-1

6)           About   loading capacity is based on pellet material of 0.65 in density and in diameter.

7)         Power:3 phases,380V,50Hz.



Optional spare parts for  China hopper dryers from factory,



Photo 1, Cyclone dust separator  for hopper dryer

  China 3 Phases 380V 50Hz White Color Hopper Dryer OEM Producer/Standard Hopper Dryer

Photo 2, Exhaust air filter for hopper dryer

China 3 Phases 380V 50Hz White Color Hopper Dryer OEM Producer/Standard Hopper Dryer



   Photo 3,  hot air recycle unit for hopper dryer

China 3 Phases 380V 50Hz White Color Hopper Dryer OEM Producer/Standard Hopper Dryer

   Photo 4,  magnetic base for hopper dryer

China 3 Phases 380V 50Hz White Color Hopper Dryer OEM Producer/Standard Hopper Dryer
