Item No.: RS-219-TPVW
China White Color Proportional Valves for Injection Molding Machine
Description of the proportional valves for mixers and loaders,
The proportional valves mix regrind and new materials in a proper proportion, and the send them back to the process machine to achieve a proportional mixing and loading effect. It features directly mounted on loaders or mounted by the pipe line. Besides, it is applicable to loaders and equipped with control box to perform when in other situations.
Features of the proportional valves,
Classy appearance, easy installation and operation.
Unique design of valve body, made material conveying more smoothly.
The performance of solenoid valve is so stable that the air cylinder acts accurately to ensure a proportional mixing of new and regrind materials.
Instant recycling the regrind material to reduce the production cost.
Features of the proportional valves control box
microprocessor control intelligent and accurate Setting ratio of virgin and regrind.
Attractive appearance, and easy to access.
Specification of the proportional valves,
Model | I Compressed air | Driven Means | Maximum MATERIAL Flow |
RS-TPV-38 | 3Kgf/cm2 | Air cylinder | 350Kg/hr |
RS-TPV-50 | 3Kgf/cm2 | ft Si Air cylinder | 550Kg/hr |
Model | Pipe Size | Dimensions H*W*D | Net weight Kg |
RS-TPV-38 | 38mm | 226x150x164 | 3.5 |
RS-TPV-50 | 50.8mm | 5 |
Note: we reserve the right to change specification without prior notice.
1 ⊙, 220V, 50Hz;
Machine color--- blue or white, or others;
Machine brand--- factory brand, OEM brand or no brand;
We do OEM!
We do B2B, B2C!
RS Plastics Machinery Co.,LTD (Zhongshan·China) |
Contact Person | Mrs. Pearl Zhu | Position | Export Manager |
Mobile Phone | 0086-13590932590 | QQ | 263567704 |
Wechat APP | zhhy18 | Skype | PEARL20128 |
E-mail | 13590932590@vip.126.com / 15113320579@vip.126.com |
Website | http://www.rs-plastics-machinery.org |
For more details of the proportional valves, please contact us for E-sheets!
For more choice of valves, plastic machinery products, please contact us for E-catalogue and Price Lists!
