Item No.: RS-TGPW
China Blade Cutter Type Strong Plastics Crusher for plastic recycling production line-White Color
E-mail: 15113320579@vip.126.com
Home Page
Description of the blade cutter granulators
The series of granulators include claw cutter series, flat cutter series and blade cutter series. They are applicable to a wide range, can meet a wide variety of requirements, able to granulate & recycle all kinds of plastics material of different texture and shapes.
BLADE CUTTER SERIES:
Blade cutter is in between claw and flat cutter blade. Suitable for recycle and restore of conventional sheets, tube plastic, profiles, packing plastics, extrusion mould products &runners. General operation adopted with airtight sealed bearing to allow long hours rotation; well designed cutter blades, to ensure the balance of pellets sizes after crushed; cutter base with special heat treatments, elegant in appearance.
Specification of the TGP blade cutter Strong plastics/ rubber crushing granulators
|
Model
|
TGP230
|
TGP300
|
TGP400
|
TGP500
|
TGP600
|
TGP800
|
|
Crushing chamber(mm)
|
230X200
|
310X200
|
410X235
|
515X290
|
610X320
|
815X470
|
|
Crushing ability(kg/h)
|
100-150
|
150-200
|
200-250
|
300-350
|
350-450
|
450-600
|
|
Stationary cutter
|
2
|
2
|
2
|
2
|
4
|
4
|
|
Rotary cutter
|
6
|
9
|
12
|
15
|
18
|
24
|
|
Power
|
KW
|
4
|
5.5
|
7.5
|
11
|
15
|
22/30
|
|
HP
|
5
|
7.5
|
10
|
15
|
20
|
30/40
|
|
Dimensions (LxWxH cm)
|
95X62X119
|
100X72X129
|
103X84X139
|
123X101X163
|
132X111X183
|
173X149X230
|
|
Net Weight(kg)
|
288
|
432
|
500
|
900
|
1100
|
2000
|
Machine color--- green, blue or grey white, or others;
Machine brand--- factory brand, OEM brand or no brand;
We do OEM!
We do B2B, B2C!
For more details of the Blade Type Powerful Granulators, please contact us for E-sheets!
For more choice of plastic granulator, plastic crusher, plastic machinery products, please contact us for E-catalogue and Price Lists!
