China White Color Soundproof Centralized Plastic Granulators Manufacturer

China White Color Soundproof Centralized Plastic Granulators Manufacturer

China White Color Soundproof Centralized Plastic Granulators Manufacturer

Product Details:

Place of Origin: China soundproof plastic granulators
Brand Name: RS or OEM
Certification: CE for plastics recycling granulators
Model Number: RS-130-TGW

Payment & Shipping Terms:

Minimum Order Quantity: 1 set of soundproof centralized plastic granulators
Price: contact us for plastics crusher price
Packaging Details: standard export packing of platics granulators
Delivery Time: 15 days according to plastic recycling granulator production
Payment Terms: T/T, West Union,MoneyGram,L/C etc
Supply Ability: 500 sets of mute centralized plastic recycling granulators
Contact Now
Detailed Product Description
Keyword: Soundproof Centralized Granulators, Plastic Granulator, Plastic Crusher, Keywords: Mute Centralized Plastics Recycling Granulators





Item No.: RS-130-TGW

China White Color Soundproof Centralized Plastic Granulators Manufacturer



Description of the plastic granulator,

tg-26/36 series is suitable for granulating a variety of plastic materials, including waste materials of injection molding, blowing molding and extrusion molding. This series is compacted in structure, easily operating, conveniently re-blending and powerful granulating ability. Gradual cutting integrated design ensures better cutting efficiency and low level noise.

China White Color Soundproof Centralized Plastic Granulators Manufacturer

The Soundproof Centralized Granulator has the following features,

Roasting blade adopts the latest 'v' cutting technology. Plastic materials will be conveyed to the center of roasting cutter, ensuring no materials pasting up on the side wall and prolong its life.

Cutter is made of imported high quality material, with high hardness, long life and wear-resisting ability. It is grinding and reusable.

Cutter base is optional. Simple and convenient blade installation technology ensures roasting blade and fixed blade adjustable in the clamp.

Granulating chamber of high hardness, processed by numerical control machine, has the following features: big thickness, high strength, wear-resisting ability, no contamination, long life and easy maintenance.

Precise design, totally enclosed sound-proofing box with low level noise.

Totally sound-proof charging box enables the granulator running with low level noise. With the material fender, plastic materials will not splash out when granulating. Balanced running, precise corporation, convenient access and easy maintenance. Charging box is uncovered by electric putter, with self-locking function, easy operation. Dust separator is for option. Height of floor stand is adjustable in a range.

Cooling water clip is helpful to efficiently reduce granulate chamber’s temperature.

Additional fixed blades could be used to enhance its granulating ability against massiveness materials.

Against the material with fiber, granulating chamber and other related parts shall be surface hardening treated.

Upon request, it can be built to comply with worldwide electrical safety standard( for example :CE).







Specification of the plastic granulator,





Model



Motor Power

(kw)



Size of Feeding Inlet(mm)



Screen Size

 (mm)

Max. Breaking

Capacity

(kg/hr)



Rotating Blades



Qty.of Paddle Blades / Qty.of Staggered Blades









Fixed Blades





Weight

(kg)

External Size LxWxH

 (mm)

TG-26

30

5. 5

200x300

⊙10

270-350

3

18

2

310

1250x810x1387

40

7. 5

260x400

⊙10

300-550

6

24

2

450

1250x910x1387

50

11

260x500

⊙10

400-650

6

30

2

650

1250x1010x1387

TG-36

60

15

360x600

⊙12

400-700

6

30

4

1000

1425x1156x1850

70

18. 5

360x700

⊙12

500-800

6

36

4

1500

1425x1256x1850

80

22

360x800

⊙12

600-900

6

42

4

1750

1515x1356x1970

Note:

1)   “ √” denotes standard, “ O ” denotes optional;

2)      ”H”   denotes increase motor power;

3)      The   material of storage box is replaced by stainless steel, marked with “R”;

4)      SKD11       is material code number of Japanese JIS standard;

5)      plastic       materials with kinds of fiber (e.g. CPVC) shall be granulated by related granulator, marked with “F” behind;

6)      Max  throughput capacity depends on diameter of screen hole and materials;

7)      Noise         level depends on plastic materials and motor configuration ;

8)      Noise         level test standards m around, 1,6m upward;

9)      To     avoid pasting up on blade, all plastic materials shall be granulated at normal temperature.

10), power supply :3⊙,380V,50HZ.





Machine color--- blue or white, or others;



Machine brand--- factory brand, OEM brand or no brand;
