Place of Origin: | China Euro auto hopper loader |
Brand Name: | RS or OEM |
Certification: | CE for 1 phase 230V 50Hz Europian automatic hopper loader |
Model Number: | RS-131-TAL-U-E |
Minimum Order Quantity: | 1 PC of euro auto hopper loader |
---|---|
Price: | contact us for hopper price |
Packaging Details: | standard export packing of loader |
Delivery Time: | 15 days according to self-contained hopper loader production |
Payment Terms: | T/T, West Union,MoneyGram,L/C etc |
Supply Ability: | 500 sets of Stand alone type auto loaders |
Keywords: | Self-contained Euro Hopper Loader, Euro Automatic Hopper Loader, | Keyword: | Stand Alone Type Auto Loaders |
---|
Item No.: RS-131-TAL-U-E
Euro Auto Hopper Loader with glass tube hopper and photoelectric valve
Description of the Euro automatic hopper loader,
Euro design with stainless steel hopper to avoid material from any pollution, in addition, it has an attractive and polished appearance and a soundproofed motor cover to reduce noise level. And convenient to move. Remote operation becomes simple and convenient by using of a detachable control panel.
The Euro automatic hopper loader has the following features,
Adjustable positioning of material hopper and base.
Wire-control controller, convenient to use.
Microprocessor control design, easy to operate and has code sender as your option.
Use 7 sects display, clear and easy to operate.
Motor start protector, carbon brush fault and running time indicator.
Circulated mixing setting which sets operation time according to proportional valve.
Cloth-made filter and equip with auto-spraying dust cleaner and pressure accumulator to decrease manual cleaning times and keeps machine in function. TAL-U has a magnetic reed switch, TAL-U-E adopts photosensor switch with high sensitive and stable quality.
Adopts carbon brush motor has features like high rotating speed, sufficient air capacity, little space occupation, moveable unit and, convenient installation.
TAL-6U-3/3U-3,both install a revolving hinge facilitate the filter screen cleaning.
Specification of the hopper loader,
With more than twenty years experience and the spirit of innovation and pursuing for excellence, we have been developing various top quality hopper loaders for conveying all kinds of plastic materials. The maximum conveying capacity of those machines is up to 400kg/hr.Stainless steel hopper and high efficiency vacuum blower are adopted for all those machines. They are also equipped with motor overload relay and material shortage alarm. Those hopper loaders are light-weighted and reliable, and also they feature at superior suction power, easy installation and convenience operation.
Model |
TAL-1.5U-E |
TAL-3U-E |
TAL-6U-E |
TAL-12U-E |
|
||||
Motor type |
Carbon brush |
||||||||
Motor power |
1.15 |
1.5 |
1.15 |
1.15 |
|
||||
Pipe Diameter(inch)
|
1.5" |
1.5" |
1.5" |
1.5" |
|
||||
Conveying pipe internal dia. (inch)
|
1.5" |
1.5" |
1.5" |
1.5" |
|
||||
Conveying capacity (kg/hr)
|
150 |
200 |
300 |
400 |
|
||||
Hopper volume (L)
|
1.5 |
3 |
6 |
12 |
|
||||
Power supply |
1 ⊙, 230V, 50Hz |
|
|||||||
Reverse cleaning kit |
Standard |
Standard |
Standard |
Standard |
|
||||
Air accumulator |
no |
no |
optional |
optional |
|
||||
Dimensions |
|
||||||||
Height H(mm) |
670 |
740 |
800 |
935 |
|
||||
Width W(mm) |
260 |
305 |
340 |
340 |
|
||||
Depth D (mm) |
325 |
370 |
410 |
410 |
|
||||
Net Weight (kg) |
11 |
13 |
16 |
18 |
|
Note
1) TAL-U-E series with glass tube hopper and photoelectric valve.
Device that can auto-cleaning filter screen(use C to refer to, for example: TAL-3U-C...),use 4~6kg/cm2 pressed air.
2) Air accumulator (apply to TAL-6U,12U model only. Use A to refer to, for example: TAL-6U-CA...).
Conveying capacity test standard:(height:4m)
Machine color--- blue or white, or others;
Machine brand--- factory brand, OEM brand or no brand;
We do OEM!
We do B2B, B2C!
RS Plastics Machinery Co.,LTD (Zhongshan·China) |
|||
Contact Person |
Mrs. Pearl Zhu |
Position |
Export Manager |
Mobile Phone |
0086-13590932590 |
|
263567704 |
Wechat APP |
zhhy18 |
Skype |
PEARL20128 |
E-mail-1 |
|||
E-mail-2 |
|||
Website |
For more details of the Euro automatic hopper loader, please contact us for E-sheets!
For more choice of hopper loaders, plastic industry machinery products, please contact us for E-catalogue and Price Lists!
If there are any questions on plastic industry machines, please feel free to contact us.
We can provide all kinds of plastics machinery solutions to meet your special demands accordingly at one-stop purchasing!
