30HP -25℃ Low Temperature Water Chillers/ Injection molding machine plastic water cooled chiller price

30HP -25℃ Low Temperature Water Chillers/ Injection molding machine plastic water cooled chiller price

    • 30HP -25℃ Low Temperature  Water Chillers/ Injection molding machine plastic water cooled chiller price
    • 30HP -25℃ Low Temperature  Water Chillers/ Injection molding machine plastic water cooled chiller price
    • 30HP -25℃ Low Temperature  Water Chillers/ Injection molding machine plastic water cooled chiller price
    • 30HP -25℃ Low Temperature  Water Chillers/ Injection molding machine plastic water cooled chiller price
  • 30HP -25℃ Low Temperature  Water Chillers/ Injection molding machine plastic water cooled chiller price

    Product Details:

    Place of Origin: China water-cooled water chillers
    Brand Name: RS or OEM
    Certification: CE for -25℃ Low Temperature Water-cooled Water Chillers
    Model Number: RS-L30WL

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set of -25℃ Low Temperature Water-cooled Water Chillers
    Price: contact us for water-cooled water chiller price
    Packaging Details: standard export packing of industry water chillers
    Delivery Time: 15 days according to water chiller production
    Payment Terms: T/T, West Union,MoneyGram,L/C etc
    Supply Ability: 500 sets of water-cooled water chillers according to China Manufacturer ability
    Contact Now
    Detailed Product Description
    Product: China Water-cooled Chillers Supplier, China Water-cooled Water Chillers Manufacturer, Keyword: China Industrial Chillers OEM Factory; China Industrial Water Chillers OEM Plant;
    Condition: New -25℃ Low Temperature Water-cooled Water Chillers Warranty: ONE Year For -25℃ Low Temperature Water-cooled Water Chillers

    Item No.: RS-L30WL


     30HP -25℃ Low Temperature Water Chillers/ Injection molding machine plastic water cooled chiller price




    If you need the price of the Low Temperature Water-cooled Water Chiller price, please do send an E-mail to: 15113320579@vip.126.com


    Home Page


    Description of the low temperature water cooled water chillers,
    The low temperature water-cooled water chillers use a single closed-loop design for pressurized refrigerant. All models are equipped with compressor and motor overload protection, phase shortage and reversal alarms, anti-freeze thermostat, pressure gauges, etc. They feature excellent performance and a long lifespan. The series of working flow is based on the basic principle of heat exchange. It is applicable to the industry that requires flow of precisely controlled chilled water, and considered as indispensable equipment for modern industry.
    30HP -25℃ Low Temperature  Water Chillers/ Injection molding machine plastic water cooled chiller price


    Features of the low temperature water-cooled water chillers,

    LOW TEMPERATURE CHILLER FEATURE

    1.Selected world class famous compressor for low-temperature refrigeration
    2.Environment-friendly refrigerant R407C,R134A,R410A,etc,no harm to the ozone field and provide excellent cooling effects.
    3.Options for temperature range: chilled water between – 5℃-30℃(depending on production needs to adopt different system configurations)
    4. According to different needs, optional for various of cooling medium (chilled water): ethylene glyco, clcohol, alcohol ternary mixture etc.; the evaporator designed as anti-corrosive and with calcium chloride water.
    5. Designed for 24 hours non-stop working condition to provide continuous cold source for all kinds of production processes.
    6. Cooling system can be built with cold water tank and circulating pump, no need for cooling tower and cooling water pumps-easy installation and maintenance.
    7. Equipped with various safety devices, providing stable performance with low noise and long life; LCD control panel enables simple and easy operations with visions of working conditions.


    30HP -25℃ Low Temperature  Water Chillers/ Injection molding machine plastic water cooled chiller price




    Specification of the low temperature water-cooled water chillers,


    Model Unit RS-L3WL RS-L5WL RS-L8WL RS-L10WL
    Cooling Capacity KW 1.77 2.67 5.64 7.66
    Kcal/h 1521 2295 4849 6585
    Compressor Input power KW 2.25 3.75 6 7.5
    Ralated power HP 3 5 8 10
    Type   Hermetic Scroll (Piston Type)
    Total Input Power KW 3 4.5 6.75 8.6
    Power   3HP-380V/50HZ(200V/220V/415V/460V 50HZ/60HZ)
    Evaporator Type   Shell and Tube/Plate Heat Exchanger
    Pipe diameter inch 1" 1" 1-1/2" 1-1/2"
    Chilled fluid flow m3/h 0.86 1.29 2.73 3.7
    Refrigerant Type   R22(R404A/R507)
    Control Method   Expansion Valve
    Condenser Type   Shell Condenser
    Pipe diameter inch 1-1/2" 1-1/2" 1-1/2" 1-1/2"
    Pump Power KW 0.75 0.75 0.75 1.1
    HP 1 1 1 1.5
    Distance m 18 18 18 20
    Safty Protection   High and low Pressure Protection,Over Load Protection,Over Temperature Protection,Phase Sequence Protection etc.
    Dimensions (L*W*H) Water Cooled mm 935*500* 883 935*500* 883 1270*650*1413 1270*650* 1413



    30HP -25℃ Low Temperature  Water Chillers/ Injection molding machine plastic water cooled chiller price

    Model Unit RS-L12WL RS-L15WL RS-L20WL RS-L25WL RS-L30WL RS-L40WL
    Cooling Capacity KW 8 8.26 13.32 16.71 19.63 24.8
    Kcal/h 6880 7102 11452 14367 16877 21323
    Compressor Input power KW 9 11.25 15 18.75 22.5 30
    Ralated power HP 12 15 20 25 30 40
    Type   Hermetic Scroll (Piston Type)
    Total Input Power KW 10.1 12.75 17.2 20.9 26.5 34
    Power   3HP-380V/50HZ(200V/220V/415V/460V 50HZ/60HZ)
    Evaporator Type   Shell and Tube/Plate Heat Exchanger
    Pipe diameter inch 1-1/2" 2" 2" 2-1/2" 2-1/2" 3"
    Chilled fluid flow m3/h 3.87 3.99 6.44 8.07 9.49 11.98
    Refrigerant Type   R22(R404A/R507)
    Control Method   Expansion Valve
    Condenser Type   Shell Condenser
    Pipe diameter inch 1-1/2" 2" 2" 2-1/2" 3" 3"
    Pump Power KW 1.1 1.5 2.2 2.2 4 4
    HP 1.5 2 3 3 5 5
    Distance m 20 20 20 20 25 20
    Safty Protection   High and low Pressure Protection,Over Load Protection,Over Temperature Protection,Phase Sequence Protection etc.
    Dimensions (L*W*H) Water Cooled mm 1270*650* 1413 1270*750* 1413 1880*880* 1650 1880*880* 1650 1880*880* 1650 2150*1080*1950





    Note,
    1. Cooling Capacity is calculated based on: inlet/outlet chilled fluid temperature:12 ℃/7 ℃, inlet/outlet cooling water temperature: 30 ℃/35 ℃.
    2. Working condition: Chilled fluid temperature: from 5 ℃ to 35 ℃. Inlet/outlet chilled fluid Temperature difference: from 3 ℃ to 8 ℃ Cooling water temperature: from 18 ℃ to 37 ℃, Inlet/outlet cooling water Temperature difference: from 3.5 ℃ to 10 ℃.
    We reserve the right to modify above information without prior notice.


     30HP -25℃ Low Temperature  Water Chillers/ Injection molding machine plastic water cooled chiller price


    Machine color--- blue or gray white and black, or others;



    Machine brand--- factory brand, OEM brand or no brand;


    We do OEM!

    We do B2B, B2C!
