    Product Details:

    Place of Origin: China separate vacuum hopper loader
    Brand Name: RS or OEM
    Certification: CE for 3 phase 400V 50Hz auto vacuum hopper receiver
    Model Number: RS-TAL-UG-13

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 PC of Euro separate Type hopper loader
    Price: contact us for hopper price
    Packaging Details: standard export packing of hopper receiver
    Delivery Time: 15 days according to Euro separate hopper receiver production
    Payment Terms: T/T, West Union,MoneyGram,L/C etc
    Supply Ability: 500 sets of Euro separate type hopper loader
    Contact Now
    Detailed Product Description
    Keywords: Euro Separate Type Hopper Receiver, Separate Hopper Receiver, Keyword: Euro Hopper Receiver, Powder Hopper Receiver;

    Item No.: RS-TAL-UG-13

     3 Phase-400V-50Hz vacuum hopper loaders for pellets & vaccum hopper loader for plastic



    Description of the Euro Separate Type Hopper Receiver

    The TAL-US series separate-vacuum hopper loaders are based on the established design and now feature more attractive appearance, better performance, and improved ease of operation. The whole range comprises of seven models equipped with vacuum blower from 1 to 15 Hp. Economy modes can be offered on request The TAL-US series separate-vacuum hopper loaders has all features that come with TAL-US series product.

    There is also double-stage blower available as an option. Different model of hopper is available for each individual output capacity needs, especially suitable for 30% and 100% powder loading.

      3 Phase-400V-50Hz vacuum hopper loaders for pellets & vaccum hopper loader for plastic

    The Euro Separate Type Hopper Receiver has the following features,

    Data backed up on EEPROM in case of power failure and does not require back up battery.

    It consists of a cyclone dust separator and a dust collective bin to effectively reduce the load of filter. Function for setting regrind mix ratio via optional TAL-12U-C/CE

    Stainless steel mesh filter as standard. Optional filter cleaning device (model denotes “C” ) and air accumulator (model denotes “A” ) available for automatic filter cleaning.

    Economy models can be offered on request.(Cloth filter as standard, second filter is removed). Optionally provide multi-functional installation frame HMB-900 with 900mm largest dia. adjusting range for selection.

    Provide both standard and optional heat-insulative Euro collective hopper TAL-6U/12U/24U for selection(Except for TAL-UGP series, which will use special collective hopper). Based on customer’ s requirements, there are two types of filters:

    The air accumulator and self-cleaning device are standard equipment.

    Optional cyclone dust separator is available for TAL—1HP2HP-UG

    On customer’ s demand, TAL-UG main unit (3.5HP above) can be equipped with either single stage or double stage blower

    Upon request, it can be built to comply with worldwide electrical safety standards (For example: CE).



    Specification of the Euro separate type hopper receiver,



    main unit



    Model



    Main Unit

    Motor power

    (KW)



    Dimensions

    HxWxD

    (mm)

    weight

    (kg)

    TAL-1HP-UG

    0.75(30)

    1205x350x530

    46

    960x350x405

    39

    TAL-2HP-UG

    1.5(30)

    1205x350x530

    46

    960x350x405

    39

    TAL-3.5HP-UG

    2.4(30)

    1380x490x570

    73

    1110x420x545

    62

    TAL-5HP-UG

    3.7(30)

    1380x490x570

    74

    1110x420x545

    65

    TAL-7.5HP-UG

    5.5(30)

    1830x585x675

    156

    1200x460x580

    112

    TAL-10HP-UG

    7.5(30)

    1830x585x675

    160

    1200x460x580

    116

    TAL-15HP-UG

    11(30)

    2100x680x800

    228

    1260xz560x800

    210

       3 Phase-400V-50Hz vacuum hopper loaders for pellets & vaccum hopper loader for plastic

    3 Phase-400V-50Hz vacuum hopper loaders for pellets & vaccum hopper loader for plastic

    3 Phase-400V-50Hz vacuum hopper loaders for pellets & vaccum hopper loader for plastic



    Hopper receiver



    Model

    Hopper Receiver

    loading pipe dia. (mm)

    Air Suction Pipe Diameter  (inch)

    Loading

    Capacity

    (kg/hr)



    Applicable Model



    Capacity

    (L)

    Dimensions

    HxWxD (mm)



    weight

    (kg)



    TAL-1HP-UG

    THR-6Ux1

    6

    4?nx?85x3fifl

    6

    1.5"

    1.5"

    300



    THR-6U-Ex1

    600x275x360

    8



    TAL-2HP-UG

    THR-12Ux1

    12

    470x315x400

    7

    1.5"

    1.5"

    500



    THR-12U-Ex1

    700x315x400

    12



    TAL-3.5HP-UG

    THR-24Ux1

    24

    690x315x400

    9

    2"

    2"

    750



    THR-24Ux1

    690x315x400

    13



    TAL-5HP-UG

    THR-24U-Ex1

    24

    1120x360x400

    9

    2"

    2"

    1000



    THR-24U-Ex1

    1120x360x400

    13



    TAL-7.5HP-UG

    THR-36Ux1

    36

    963x315x400

    11

    2"

    2.5”

    1200




    TAL-10HP-UG

    THR-36Ux1

    36

    930x315x400

    11

    2"

    2.5"

    1600




    TAL-15HP-UG

    THR-48UX1

    48

    975x350x485

    15

    2.5"

    3"

    2000






     3 Phase-400V-50Hz vacuum hopper loaders for pellets & vaccum hopper loader for plastic3 Phase-400V-50Hz vacuum hopper loaders for pellets & vaccum hopper loader for plastic

    3 Phase-400V-50Hz vacuum hopper loaders for pellets & vaccum hopper loader for plastic3 Phase-400V-50Hz vacuum hopper loaders for pellets & vaccum hopper loader for plastic    3 Phase-400V-50Hz vacuum hopper loaders for pellets & vaccum hopper loader for plastic

    Note:

    1)           “D” denote as double stage blower. (126 denote as one to six receiver system);

    2)           “E” denote as machine direct mount Receiver (glass type);

    3)           For hopper inside polished, add “P ” at model behind;

    4)           It’ s available to select ACF-1 cyclone dust separator;

    5)           TAL-3.5HP-UG and above models has vacuum breaking valve to protect the blower;

    6)           Noise level 75db;

    7)           Test condition of conveying capacity. Plastic material of bulk density 0.65;

    Diameter 3-5mm, Vertical conveying height:4m, Horizontal conveying distance:5m;

    Power supply:3 phase,400V,50Hz;



    Machine color--- blue or white, or others;



    Machine brand--- factory brand, OEM brand or no brand;
