200 degree 9KW oil type mold temperature controller for heating/ Plastic Injection Oil Heater Companies

200 degree 9KW oil type mold temperature controller for heating/ Plastic Injection Oil Heater Companies

    • 200 degree 9KW oil type mold temperature controller for heating/ Plastic Injection Oil Heater Companies
    • 200 degree 9KW oil type mold temperature controller for heating/ Plastic Injection Oil Heater Companies
    • 200 degree 9KW oil type mold temperature controller for heating/ Plastic Injection Oil Heater Companies
    • 200 degree 9KW oil type mold temperature controller for heating/ Plastic Injection Oil Heater Companies
  • 200 degree 9KW oil type mold temperature controller for heating/ Plastic Injection Oil Heater Companies

    Product Details:

    Place of Origin: China oil mold temperature controller
    Brand Name: RS or OEM
    Certification: CE for China oil mold temperaturer controller manufacturer
    Model Number: RS-TM-O

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set of Oil Mold Temperature Controller
    Price: contact us for Oil Mold Temperature Controller price
    Packaging Details: standard export packing of Oil Mold Temperature Controller
    Delivery Time: 15 days according to Oil Mold Temperature Controller production
    Payment Terms: T/T, West Union,MoneyGram,L/C etc
    Supply Ability: 500 sets of Oil Mold Temperature Controller according to China Manufacturer ability
    Contact Now
    Detailed Product Description
    Product: China Standard Oil Mold Temperature Controller Manufacturer, China Oil Heaters OEM Factory, Keyword: China Industrial Mould Temperature Controllers Supplier;MTC;
    Condition: New Oil Type Mold Temperature Controller Warranty: ONE Year For Oil Type Mould Temperature Controller

    Item No.: RS-TM-O





    200 degree 9KW oil type mold temperature controller for heating/ Plastic Injection Oil Heater Companies





    If you need the price of the Standard Oil Type Mold Temperature Controller price, please do send an E-mail to: 15113320579@vip.126.com



    Home Page





    Description of the Standard Oil Type Mold Temperature Controller,Oil Type Mold Temperature Controller,

    The RS-TM-O series of oil heaters are used to heat up the mould and maintain this temperature, although they can be used in other similar applications. High temperature oil from the mould is returned to the cooling tank and cooled by indirect cooling. It is then pressurised by the high-pressure pump, sent to the heating tank and finally to the mould with a constant temperature and accurate PID multi-stage temperature control system.



    200 degree 9KW oil type mold temperature controller for heating/ Plastic Injection Oil Heater Companies





    Features of the Standard Oil Type Mold Temperature Controller,Oil Type Mold Temperature Controller,

    PID multi-stage temperature control system can maintain a mould temperature with accuary of ± 1℃

    Multiple safety devices can automatically detect abnormal performance and indicate this via visible alarm.

    Reliable mains isolator to cut power supply in case of emergency.

    High temperature heat transfer oil is stable up to 200℃,suitable for long and continuous operation.

    Attractive appearance,easy to access and maintain.



    200 degree 9KW oil type mold temperature controller for heating/ Plastic Injection Oil Heater Companies





    Specification of the iStandard Oil Type Mold Temperature Controller,ndu

    strial oil mould temperature controllers,

    Model

    Max

    Temperature

    Pump



    Heatei

    <kW)

    Pump

    Power

    <kV/)

    Max pump Flow

    (L/rnin)

    MaxPump Pressure



    (bar)

    Heating

    Tank Number

    Main/sub oil tank (L)

    Cooling

    Method

    Mould

    Coupling

    (Inch)

    Demensions

    (HxWxD)

    (mm)

    N.W.

    Kg

    RS-TM-600

    200°C

    6

    0.55

    27

    3.8

    1

    6/3.2

    Indirect

    3/8"(2x2)

    635x280x740

    65

    RS-TM-900

    9

    0.75

    42

    5.0

    1

    6/3.2

    3/8"(2x2)

    635x280x740

    70

    RS-TM-1200

    12

    1.5

    74

    6.2

    1

    6.8/11.8

    3/8"(4X2)

    795x340x845

    100

    RS-TM-2400

    24

    3

    130

    8.0

    2

    11/16

    1" (1x2)

    900x390x935

    145

    RS-TM-3600

    36

    4

    200

    8.0

    3

    14/16

    1 V4" (1 x2)

    900x385x980

    155

    Note,

    1) “ D” stands for dual-heating zones, “ HT ” stands for high temperature;

    2)    Pump    testing standard:Power of 50Hz,purified water at 20

    3),Power      Supply:3⊙ ,380V,50Hz



    200 degree 9KW oil type mold temperature controller for heating/ Plastic Injection Oil Heater Companies







    Application of the iStandard Oil Type Mold Temperature Controller,ndustrial oil mould temperature controllers,



    The Standard Oil Type Mold Temperature Controller is suitable for Reaction kettles, extrusion forming equipment, rubber forming machinery, cast film production lines, cable extrusion production lines, the dies for precise plastic molding, the dies for the compression casting of magnesium/aluminum/zinc alloy, roller pressing applied in rubber/plastic and leather industries, crude oil heating of the oil sinks on tank ships, paper making industry, bottle blowing, and so on.



    The  Standard Oil Type Mold Temperature Controller has been designed to maintain a constant temperature, using water or oil as medium. Mold temperature controller is used to control temperature in various industrial fields.



    200 degree 9KW oil type mold temperature controller for heating/ Plastic Injection Oil Heater Companies





    Working Principle of the industrial oil mould temperature controllers,

    High temperature oil returns to the machine and then be pressured by pump to the heaters, After being heated, oil will be forced to mould and continue the circle. In the process, if the temperature is too high, the system will activate the solenoid valve to let return oil cool down the temp, directly till the oil temp, is down to the system requirement. If the temp, keep rising and reach to the set point of EGO, the system will alarm and stop working if cooling water pressure doesn't reach set point.

    200 degree 9KW oil type mold temperature controller for heating/ Plastic Injection Oil Heater Companies







    Model Selection Guide for Oil Mold Temperature Controller,

    Mould Clamping Force (T)

    Moulding Capacity

    Kg/hr

    Pump Flow

    L/min



    25U  Below 25T

    3T Below 3T

    10



    25-50

    3-6

    25



    200-300

    25-40

    40

    300-650

    40-80

    60

    650 above

    80 above

    120
