    Product Details:

    Place of Origin: China Air-cooled Screw Chiller
    Brand Name: RS or OEM
    Certification: CE for China Air-cooled Screw Chiller
    Model Number: RS-LF40AS

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set of Air-cooled Screw Chiller
    Price: contact us for Air-cooled Screw Chiller price
    Packaging Details: standard export packing of Air-cooled Screw Chiller
    Delivery Time: 15 days according to Air-cooled Screw Chiller production
    Payment Terms: T/T, West Union,MoneyGram,L/C etc
    Supply Ability: 500 sets of Air-cooled Screw Chiller according to China Manufacturer ability
    Contact Now
    Detailed Product Description
    Product: Air-cooled Screw Chiller /Environmental Friendly Chillers, China Water-cooled Chillers Supplier, China Water-cooled Water Chil Keyword: Air-cooled Screw Chiller /Heat And Cold Chillers 2-in-1 ,China Industrial Chillers OEM Factory; China Industrial Water Chiller
    Condition: New Air-cooled Screw Chiller Warranty: ONE Year For Air-cooled Screw Chiller

    Item No.: RS-LF40AS



     RS-LF40AS China air cooled water chiller /Air Screw Chilller For Philippines/Air-cooled Screw Chiller Price





    E-mail: 15113320579@vip.126.com

    Home Page




    Description of the Air Cooled Screw Chillers ,


    The Air Cooled Screw Chillers use a single closed-loop design for pressurized refrigerant. All models are equipped with compressor and motor overload protection, phase shortage and reversal alarms, anti-freeze thermostat, pressure gauges, etc. They feature excellent performance and a long lifespan. The series of working flow is based on the basic principle of heat exchange. It is applicable to the industry that requires flow of precisely controlled chilled water, and considered as indispensable equipment for modern industry.



    RS-LF40AS China air cooled water chiller /Air Screw Chilller For Philippines/Air-cooled Screw Chiller Price

    Specification of the Air Cooled Screw Chillers ,



    Model Unit RS-LF40AS RS-LF50AS RS-LF60AS RS-LF75AS RS-LF100AS
    Cooling Capacity KW 103 129 149 210 259
    Kcal/h 88924 111714 128226 180600 223428
    Input Power KW 44 54 64 84 109
    Refrigerant mass flow rate control Type Expansion valve
    Refrigerant R22(R407C)
    Compressor Type Semi-closed screw type
    Quantity pcs 1 2
    Starting mode Y-△ starting
    Power control 0-25-50-75-100
    Power 3HP-380V/50HZ (200V/220V/415V 50HZ/60HZ)
    Evaporator Type Shell and Tube
    Cooling water flow m3/h 18 23 26 26 46
    Pipe diameter inch 3" 3" 3" 4" 4"
    Condenser Type Effective air-cooled copper pipe with aluminium sheet
    Fan Type   high power axial flow fan
    Fan power KW 6.4 9 9 13.5 18
    Air volume m3/h 40000 51000 63000 80000 105000
    Safty Protection High and low Pressure Protection,Over Load Protection,Over Temperature Protection,Phase Sequence Protection,water flow switch,antifreezing protection etc.
    Dimensions (L*W*H) mm 2150*2000*1850 2400*2250*1880 2480*2300*1980 2600*2300*1980 4050*2100*2020
    Weight KG 1300 1620 1930 2260 3340
    Unit Conversion 1KW=860Kcal/hr 1RT=3024Kcal/hr 1Btu/hr=0.252Kcal/hr



    RS-LF40AS China air cooled water chiller /Air Screw Chilller For Philippines/Air-cooled Screw Chiller Price



    Model Unit RS-LF120AS RS-LF150AS RS-LF170AS RS-LF200AS RS-LF240AS
    Cooling Capacity KW 298 420 496 564 676
    Kcal/h 256452 362300 426560 485040 581360
    Input Power KW 127 168 197 229 270
    Refrigerant mass flow rate control Type Expansion valve
    Refrigerant R22(R407C)
    Compressor Type Semi-closed screw type
    Quantity pcs 1 2
    Starting mode Y-△ starting
    Power control 0-25-50-75-100
    Power 3HP-380V/50HZ (200V/220V/415V 50HZ/60HZ)
    Evaporator Type Shell and Tube
    Cooling water flow m3/h 52 71 86 100 117
    Pipe diameter inch 5" 5" 6" 6" 6"
    Condenser Type Effective air-cooled copper pipe with aluminium sheet
    Fan Type   high power axial flow fan
    Fan power KW 18 27 27 36 36
    Air volume m3/h 122000 155000 175000 205000 250000
    Safty Protection High and low Pressure Protection,Over Load Protection,Over Temperature Protection,Phase Sequence Protection,water flow switch,antifreezing protection etc.
    Dimensions (L*W*H) mm 4050*2100*2050 2400*3400*1880 3150*4200*2200 2600*4550*1980 4050*4200*2050
    Weight KG 3850 4200 4450 3670 4860
    Unit Conversion 1KW=860Kcal/hr 1RT=3024Kcal/hr 1Btu/hr=0.252Kcal/hr



     RS-LF40AS China air cooled water chiller /Air Screw Chilller For Philippines/Air-cooled Screw Chiller Price

    Note: 1.Cooling Capacity is calculated based on: inlet/outlet chilled fluid temperature:12℃/7℃,inlet/outlet cooling water temperature:30℃/40℃.

    2.Working condition: Chilled fluid temperature: from 5℃ to 35℃. Inlet/outlet chilled fluid Temperature difference: from 3℃ to 8℃

    Cooling water temperature: from below 35℃, Inlet/outlet cooling air Temperature difference: from 3℃ to 8℃.

    We reserve the right to modify above information without prior notice.


    RS-LF40AS China air cooled water chiller /Air Screw Chilller For Philippines/Air-cooled Screw Chiller Price




    Machine color--- blue or gray white, or others;



    Machine brand--- factory brand, OEM brand or no brand;



    We do OEM!



    We do B2B, B2C!
