China 1-to-4 Separate Type Vacuum Powder Hopper Loader Manufacturer

China 1-to-4 Separate Type Vacuum Powder Hopper Loader Manufacturer

China 1-to-4 Separate Type Vacuum Powder Hopper Loader Manufacturer

Product Details:

Place of Origin: China separate vacuum powder hopper loader
Brand Name: RS or OEM
Certification: CE for 3 phase 400V 50Hz auto vacuum hopper receiver
Model Number: RS-TAL-UGP-2

Payment & Shipping Terms:

Minimum Order Quantity: 1 PC of Euro separate Type powder vacuum hopper loader
Price: contact us for hopper price
Packaging Details: standard export packing of receiver
Delivery Time: 15 days according to Euro separate hopper receiver production
Payment Terms: T/T, West Union,MoneyGram,L/C etc
Supply Ability: 500 sets of Euro separate type hopper loader
Contact Now
Detailed Product Description
Keywords: Euro Separate Type Powder Hopper Receiver, Separate Hopper Receiver, Keyword: Euro Hopper Receiver, Powder Vacuum Hopper Receiver;

Item No.: RS-TAL-UGP-2

 China 1-to-4 Separate Type Vacuum Powder Hopper Loader Manufacturer



Description of the Euro Separate Type Hopper Receiver

The TAL-US series separate-vacuum hopper loaders are based on the established design and now feature more attractive appearance, better performance, and improved ease of operation. The whole range comprises of seven models equipped with vacuum blower from 1 to 15 Hp. Economy modes can be offered on request The TAL-US series separate-vacuum hopper loaders has all features that come with TAL-US series product.

There is also double-stage blower available as an option. Different model of hopper is available for each individual output capacity needs, especially suitable for 30% and 100% powder loading.

   China 1-to-4 Separate Type Vacuum Powder Hopper Loader Manufacturer



The Euro Separate Type Hopper Receiver has the following features,

Data backed up on EEPROM in case of power failure and does not require back up battery.

It consists of a cyclone dust separator and a dust collective bin to effectively reduce the load of filter. Function for setting regrind mix ratio via optional TAL-12U-C/CE

Stainless steel mesh filter as standard. Optional filter cleaning device (model denotes “C” ) and air accumulator (model denotes “A” ) available for automatic filter cleaning.

Economy models can be offered on request.(Cloth filter as standard, second filter is removed). Optionally provide multi-functional installation frame HMB-900 with 900mm largest dia. adjusting range for selection.

Provide both standard and optional heat-insulative Euro collective hopper TAL-6U/12U/24U for selection(Except for TAL-UGP series, which will use special collective hopper). Based on customer’ s requirements, there are two types of filters:

The air accumulator and self-cleaning device are standard equipment.

Optional cyclone dust separator is available for TAL—1HP2HP-UG

On customer’ s demand, TAL-UG main unit (3.5HP above) can be equipped with either single stage or double stage blower

Upon request, it can be built to comply with worldwide electrical safety standards (For example: CE).



Specification of the Euro separate type hopper receiver,



main unit



Model



Main Unit

Motor power

(KW)



Dimensions

HxWxD

(mm)

weight

(kg)

TAL-1HP-UG

0.75(30)

1205x350x530

46

960x350x405

39

TAL-2HP-UG

1.5(30)

1205x350x530

46

960x350x405

39

TAL-3.5HP-UG

2.4(30)

1380x490x570

73

1110x420x545

62

TAL-5HP-UG

3.7(30)

1380x490x570

74

1110x420x545

65

TAL-7.5HP-UG

5.5(30)

1830x585x675

156

1200x460x580

112

TAL-10HP-UG

7.5(30)

1830x585x675

160

1200x460x580

116

TAL-15HP-UG

11(30)

2100x680x800

228

1260xz560x800

210





Hopper receiver



Model

Hopper Receiver

loading pipe dia. (mm)

Air Suction Pipe Diameter  (inch)

Loading

Capacity

(kg/hr)



Applicable Model



Capacity

(L)

Dimensions

HxWxD (mm)



weight

(kg)



TAL-1HP-UG

THR-6Ux1

6

4?nx?85x3fifl

6

1.5"

1.5"

300



THR-6U-Ex1

600x275x360

8



TAL-2HP-UG

THR-12Ux1

12

470x315x400

7

1.5"

1.5"

500



THR-12U-Ex1

700x315x400

12



TAL-3.5HP-UG

THR-24Ux1

24

690x315x400

9

2"

2"

750



THR-24Ux1

690x315x400

13



TAL-5HP-UG

THR-24U-Ex1

24

1120x360x400

9

2"

2"

1000



THR-24U-Ex1

1120x360x400

13



TAL-7.5HP-UG

THR-36Ux1

36

963x315x400

11

2"

2.5”

1200




TAL-10HP-UG

THR-36Ux1

36

930x315x400

11

2"

2.5"

1600




TAL-15HP-UG

THR-48UX1

48

975x350x485

15

2.5"

3"

2000








 China 1-to-4 Separate Type Vacuum Powder Hopper Loader Manufacturer    China 1-to-4 Separate Type Vacuum Powder Hopper Loader Manufacturer

Note:

1)           “D” denote as double stage blower. (126 denote as one to six receiver system);

2)           “E” denote as machine direct mount Receiver (glass type);

3)           For hopper inside polished, add “P ” at model behind;

4)           It’ s available to select ACF-1 cyclone dust separator;

5)           TAL-3.5HP-UG and above models has vacuum breaking valve to protect the blower;

6)           Noise level 75db;

7)           Test condition of conveying capacity. Plastic material of bulk density 0.65;

Diameter 3-5mm, Vertical conveying height:4m, Horizontal conveying distance:5m;

Power supply:3 phase,380V,50Hz;



Machine color--- blue or white, or others;



Machine brand--- factory brand, OEM brand or no brand;



We do OEM!



We do B2B, B2C!
