    Product Details:

    Place of Origin: China color mixer
    Brand Name: RS or OEM
    Certification: CE for volumetric double color mixer
    Model Number: RS-218-TCM-D

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set of volumetrc dosing color mixer
    Price: contact us for plastics color mixer price
    Packaging Details: standard export packing of volumetric dosers
    Delivery Time: 30 days according to volumetric dosing color mixer production
    Payment Terms: T/T, West Union,MoneyGram,L/C etc
    Supply Ability: 500 sets of volumetric double color mixers
    Contact Now
    Detailed Product Description
    Keywords: Volumetric Double Color Mixer, Volumetric Dosing Color Mixer, Keyword: Plastic Mixing Machine,volumetric Dosers;

    Item No.: RS-218-TCM-D

    China Volumetric Double-Color Mixer OEM Supplier



    Description of the volumetric double color mixer,

    The volumetric dosers color mixer are suitable for auto-proportional mixing of new material, regrind, master batch and additives. A brushless DC motor is used in this series. The microprocessor accurately controls rotation of the high precise dosing screws to squeeze out materials with an accuracy of 1% form set point. A gear motor with deceleration ratio of 30:1 or 100:1 is coupled to a dosing screw of six models with output ranging from 0.1~32kg/hr. Double color doser can be supplied to match with two single color doser if required by clients.

      China Volumetric Double-Color Mixer OEM Supplier


    Features of the volumetric color mixer


    Everlasting data memorizer and settings storage.
    Use brushless DC motor? and free from maintenance.
    Microprocessor control, intelligent and accurate in calculation.
    External signals can be directly interfaced with the control box.
    Dosing screws are chrome plated for durability.
    Unit is comprised of standard modules for ease of cleaning, disassembly and interchangeability.
    Three-tubes hopper magnet is equipped at the base of the single color doser to absorb metal impurities so to prevent the screw of molding machine from damage.
    Single color doser takes base? blender as an option to make blending more evenly.
    Blender built-in a standard accessory for double color doser and it can meet client's need for double blending.
    Main material hopper is a standard accessory for double color mixer. It is optional for single color mixer.



    Specification of the volumetric color mixer,



    Model



    RS-TCM-D-30/30



    RS-TCM-D-30/100



    RS-TCM-D-100/100

    Motor Power ( kw )



    0.06x2

    0.06x2

    0.06x2

    Motor speed ( r.p.m. )



    0-3000

    0-3000

    0-3000

    Mixer Power ( kw )



    0.09

    0.09

    0.09

    External Screw Dia. ( mm )



    * *

    * *

    * *

    Output Capacity ( kg/hr)



    *

    *

    *



    Storage Bin  L

    10

    10

    10



    Gear Ratio

    30:1/100:1

    30:1/100:1

    30:1/100:1

    Main Material  Hopper

    Standard

     Standard

     Standard

    Mixer

     Standard

     Standard

     Standard

    Floor Stands



    Optional



    Optional



    Optional



    Dimensions



    H (mm|

    580

    580

    580

    W (mm)

    900

    900

    900

    D  mm

    290

    290

    290

    N.W. kg

    50

    50

    50








    Note:1) “ * ” means the output capacity depends on model selected, data of the single color mixer/doser can be a reference. For example: TCM-D-38-16/38-14,output capacity l .7-52kg/hr.

    2)            “ ** ” stands for external dia. of screw is up to model selected.

    3)            Single-color   volumetric mixer adds to mixer, add “MS” at the back of the model.

    4)            AII  output capacity from above models are base on data from density 1.2,dia. 2-3 mm master batch in a test criteria of continuous running.



    5), Voltage:1⊙,220V,50Hz.
