    Product Details:

    Place of Origin: China
    Brand Name: RS
    Certification: CE ,CCC
    Model Number: RSD-50H

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Packaging Details: wooden case for honeycomb dehumidifier
    Delivery Time: 10-20 days
    Payment Terms: T/T, Western Union, MoneyGram
    Supply Ability: 500 sets/day
    Contact Now
    Detailed Product Description
    Air Flow: 50m3 Per Hour For Honeycomb Dehumidifier Colour: Blue Or White For Honeycomb Dehumidifier
    Dew Point: -40 Degree Centigrade Keyword: Dessciant Rotor Honeycomb Dehumidifier

    Honeycomb Dehumidifying Dryer/ Industrial Honeycomb Dehumidifier Equipment For Plastic Material granule



    If you need the price of the Honeycomb Dehumidifier, please do send an E-mail to:

    13590932590@vip.126.com



    Home Page





    Description of the China honeycomb dehumidifier,

    The honeycomb dehumidifiers are mainly used to dry hygroscopic engineering plastics. A honeycomb-rotor is used in this series to offer effective drying. We offer two types of honeycomb rotors:H4 and H5 models that, under ideal conditions, can supply dehumidified dry air with a dew-point down to -40 and -50 centi-degree respectively.The TD-H series offers accurate P.I.D temperature control as optional features. This series comprises 14 models of honeycomb dehumidifiers, the largest of which can provide dry air up to a volume of 4000m3/hr.

    Honeycomb Dehumidifying Dryer/ Industrial Honeycomb Dehumidifying Equipment For Plastic Material granule

    Features of the China honeycomb dehumidifier,

    The honeycomb dehumidifiers use P.I.D temperature control system, has regenerating temperature settings and real temperature display function.
    Equips with dehumidifying heater and temperature control gauge as options to dry and dehumidify the raw material.
    The dehumidifying system features two condensers to ensure a low return air temperature and low dew-point,
    Main power switch with mechanical chain lock function.



    Honeycomb Dehumidifying Dryer/ Industrial Honeycomb Dehumidifying Equipment For Plastic Material granule



    Dessciant Honeycomb dehumidifier specification ;



    Specification of the honeycomb dehumidifier,







    Model

    30H 50H 80H 120H 150H 200H 300H 400H 500H 700H 1000H 1500H 2000H 3000H
    Process Air Flow ( rrf/hr) 30 50 80 120 150 200 300 400 500 700 1000 1500 2000 3000

    Process Heater (kw)



    3 3.9 6 6 7.2 12 15 18 21 24 32 58 80 96



    Process Blower ( kw)



    0.2 0.4 0.75 0.75 1.5 1.5 3 3.4 5.5 5.5 9 9x2 13x2 13x3

    (



    Regen .heater kw)

    0.2 0.2 0.2 0.2 0.4 0.4 0.75 0.75 1.5 1.5 2.4 3.4 5.5 7.5



    Regen. Blower (kw)



    3 3 3.5 3.5 4 5.4 7.2 7.2 10 10 15 20 20 30
    Pipe Dia. t ( inch ) 2" 2" 2" 2" 2.5" 2.5" 3" 3" 4" 4" 5" 6" 8" 8"



    Voltage

    3⊙,380V,50Hz



    Dimensions

    H(mm) 1260 1260 1360 1360 1560 1560 1745 1745 1935 1935 2145 2145 2060 2500
    W(mm) 480 480 530 530 660 660 700 700 900 900 1300 1300 1410 1600
    D(mm) 755 755 820 820 1050 1050 1255 1255 1380 1380 1550 1910 2150 2160
    Weight( kg ) 80 80 120 140 215 225 240 280 290 300 400 510 630 760

    Note:*Process heater is optional to be used with a drying hopper.

    Note: we reserve the right to change specification without prior notice.









    Honeycomb Dehumidifying Dryer/ Industrial Honeycomb Dehumidifying Equipment For Plastic Material granule

    Honeycomb dessciant wheel rotor material with two kinds: molecular sieve and silica gel which made in sweden. The honeycomb dehumidifier dew point usually reach -40 degree centagrade .

    Honeycomb Dehumidifying Dryer/ Industrial Honeycomb Dehumidifying Equipment For Plastic Material granule



    Honeycomb dehumidifier moisture content PPM diagram ;

    Honeycomb Dehumidifying Dryer/ Industrial Honeycomb Dehumidifying Equipment For Plastic Material granule







    Machine color--- blue or grey white, or others;


    Honeycomb Dehumidifying Dryer/ Industrial Honeycomb Dehumidifying Equipment For Plastic Material granule
